Product Description
Built for demanding construction environments, this 2017 Sany SY245H excavator delivers exceptional operator control and productivity. Advanced hydraulic systems provide precise handling across diverse terrain conditions, while the reinforced undercarriage ensures superior stability during heavy lifting operations.
Key operator advantages include:
- Enhanced cabin visibility with panoramic glass design for improved site awareness
- Ergonomic joystick controls reducing operator fatigue during extended shifts
- Low-vibration cabin mounting system for comfortable operation
- Intuitive dashboard layout with clear instrumentation displays
Featuring Tier 4 compliant engine technology, this excavator meets stringent emission standards while maintaining robust performance. The spacious operator compartment includes adjustable seating and climate control for all-weather productivity. Located in Yichun, Jiangxi, this machine represents proven reliability in China's construction sector.
Designed for contractors prioritizing operational efficiency and operator comfort, the SY245H combines Sany's engineering expertise with practical jobsite functionality.
| Specifications | Value |
|---|---|
| No. | 991864 |
| Tonnage (tons) | 25 |
| Working weight (kg) | 25500 |
| Bucket capacity (m³) | 1.4 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Deutz |
| Rated power (kw/rpm) | 150/2100 |
| Ground specific pressure (Kpa) | 52.5 |
| Rotation speed (rpm) | 10 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 175(187) |
| Rod digging force (kN) | 120(129) |
| Travel speed (km/h) | 5.8/3.7 |
| Total transport length (mm) | 10290 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3255 |
| Full cab height (mm) | 3255 |
| Minimum ground clearance (mm) | 470 |
| Minimum turning radius of front working device (mm) | 3800 |
| Back end turning radius (mm) | 3105 |
| Onboard width (mm) | 3045 |
| Total track length (mm) | 4445 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3640 |
| Maximum height at minimum turning radius (mm) | 8016 |
| Maximum digging radius (mm) | 10225 |
| Maximum digging depth (mm) | 6705 |
| Maximum excavation height (mm) | 9745 |
| Maximum unloading height (mm) | 6715 |
| Maximum vertical digging depth (mm) | 5675 |
