Product Description
Available now from our 江苏常州 facility, this 2019 Sany SY245H excavator delivers immediate deployment without factory lead times. Powered by a robust D06FRC 6-cylinder engine producing 147kW at 2100rpm, this 24-ton workhorse combines proven hydraulic performance with field-ready reliability. With 175kN bucket digging force and a maximum reach of 10,225mm, it handles demanding excavation tasks across construction, mining, and infrastructure projects.
- Operating weight: 25,500kg with 1.3-1.5m³ bucket capacity
- Water-cooled engine: 6.373L displacement, 750N·m maximum torque
- Fast shipping from 江苏常州 to ports and job sites nationwide
- Maximum digging depth: 6,705mm | Maximum height: 9,745mm
- 475L fuel tank and 277L hydraulic reservoir for extended operation
- Track dimensions: 600mm width, 3,640mm ground contact length
Skip months of factory waiting. This machine is inspected, serviced, and ready for immediate dispatch from 江苏常州. Secure your equipment today and maintain project momentum with fast logistics support across China and international markets.
| Specifications | Value |
|---|---|
| No. | 1018961 |
| Tonnage (tons) | 24 |
| Working weight (kg) | 25500 |
| Bucket capacity (m³) | 1.3~1.5(1.5) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | D06FRC |
| Rated power (kw/rpm) | 147/2100 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 750/1350 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.373 |
| Ground specific pressure (Kpa) | 53.2 |
| Rotation speed (rpm) | 10.6 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 175 |
| Rod digging force (kN) | 120 |
| Travel speed (km/h) | 5.4/3.4 |
| Fuel Tank (L) | 475 |
| Hydraulic Tank (L) | 277 |
| Engine Oil changes (L) | 29 |
| Total transport length (mm) | 10290 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3190 |
| Full cab height (mm) | 3255 |
| Minimum ground clearance (mm) | 470 |
| Minimum turning radius of front working device (mm) | 3800 |
| Back end turning radius (mm) | 3105 |
| Onboard width (mm) | 3045 |
| Total track length (mm) | 4445 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3640 |
| Maximum height at minimum turning radius (mm) | 8016 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 9 |
| Number of track plates (single side) (PCS) | 49 |
| Maximum digging radius (mm) | 10225 |
| Maximum digging depth (mm) | 6705 |
| Maximum excavation height (mm) | 9745 |
| Maximum unloading height (mm) | 6715 |
see more
