Product Description
This 2019 Sany SY245H hydraulic excavator offers reliable performance for medium to heavy-duty earthmoving applications. Manufactured by Sany Heavy Industry, one of China's leading construction equipment producers, this model combines proven engineering with practical operational efficiency.
The SY245H is designed for versatility across construction, mining, and infrastructure projects. Its hydraulic system delivers consistent digging force and cycle times, while the operator cabin provides adequate visibility and control access for extended work shifts.
Key features include:
- 2019 model year with documented service history
- Sany's established 24-ton class platform
- Suitable for excavation, loading, and material handling
- Currently located in Sichuan, China
- Available for inspection by qualified buyers
This unit represents a cost-effective solution for contractors seeking dependable excavation capacity. Contact us for detailed specifications, operating hours, and shipping arrangements.
| Specifications | Value |
|---|---|
| No. | 1072592 |
| Tonnage (tons) | 24 |
| Working weight (kg) | 25500 |
| Bucket capacity (m³) | 1.3~1.5(1.5) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | D06FRC |
| Rated power (kw/rpm) | 147/2100 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 750/1350 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.373 |
| Ground specific pressure (Kpa) | 53.2 |
| Rotation speed (rpm) | 10.6 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 175 |
| Rod digging force (kN) | 120 |
| Travel speed (km/h) | 5.4/3.4 |
| Fuel Tank (L) | 475 |
| Hydraulic Tank (L) | 277 |
| Engine Oil changes (L) | 29 |
| Total transport length (mm) | 10290 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3190 |
| Full cab height (mm) | 3255 |
| Minimum ground clearance (mm) | 470 |
| Minimum turning radius of front working device (mm) | 3800 |
| Back end turning radius (mm) | 3105 |
| Onboard width (mm) | 3045 |
| Total track length (mm) | 4445 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3640 |
| Maximum height at minimum turning radius (mm) | 8016 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 9 |
| Number of track plates (single side) (PCS) | 49 |
| Maximum digging radius (mm) | 10225 |
| Maximum digging depth (mm) | 6705 |
| Maximum excavation height (mm) | 9745 |
| Maximum unloading height (mm) | 6715 |
