Product Description
With a robust build from 2020, the Sany SY245H(国四) offers operators in 四川 an unparalleled experience. From its location, this excavator provides exceptional handling and stability, ensuring precise control even on challenging terrains. Inside the cabin, operators benefit from excellent visibility, enhancing safety and efficiency on the job site. Designed with the operator in mind, this model integrates ergonomic controls and a spacious, comfortable interior, making long hours of operation less taxing. Whether you're maneuvering through tight spaces or executing complex tasks, the SY245H(国四) delivers reliable performance and ease of use.
- Exceptional handling and stability for precise operations
- Enhanced cabin visibility for improved safety and productivity
- Ergonomically designed controls and a comfortable interior
| Specifications | Value |
|---|---|
| No. | 1002051 |
| Tonnage (tons) | 25 |
| Working weight (kg) | 25500 |
| Bucket capacity (m³) | 1.4 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Deutz |
| Rated power (kw/rpm) | 150/2100 |
| Ground specific pressure (Kpa) | 52.5 |
| Rotation speed (rpm) | 10 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 175(187) |
| Rod digging force (kN) | 120(129) |
| Travel speed (km/h) | 5.8/3.7 |
| Total transport length (mm) | 10290 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3255 |
| Full cab height (mm) | 3255 |
| Minimum ground clearance (mm) | 470 |
| Minimum turning radius of front working device (mm) | 3800 |
| Back end turning radius (mm) | 3105 |
| Onboard width (mm) | 3045 |
| Total track length (mm) | 4445 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3640 |
| Maximum height at minimum turning radius (mm) | 8016 |
| Maximum digging radius (mm) | 10225 |
| Maximum digging depth (mm) | 6705 |
| Maximum excavation height (mm) | 9745 |
| Maximum unloading height (mm) | 6715 |
| Maximum vertical digging depth (mm) | 5675 |
