2020 Sany SY245H

1/9
Buy Sany SY245H Used Excavator / 1
Buy Sany SY245H Used Excavator / 2
Buy Sany SY245H Used Excavator / 3
Buy Sany SY245H Used Excavator / 4
Buy Sany SY245H Used Excavator / 5
Buy Sany SY245H Used Excavator / 6
Buy Sany SY245H Used Excavator / 7
Buy Sany SY245H Used Excavator / 8
Buy Sany SY245H Used Excavator / 9

Product Description

This 2020 Sany SY245H hydraulic excavator represents a well-maintained earthmoving machine from one of China's leading heavy equipment manufacturers. Manufactured in June 2020, this unit has been primarily deployed in earthwork applications, demonstrating the robust performance expected from Sany's 24-ton class excavators.

Currently located in Sichuan, China, this machine is available for immediate delivery in original factory condition. The SY245H is known for its reliable Isuzu engine, efficient hydraulic system, and operator-focused cab design that reduces fatigue during extended shifts.

  • Year: 2020 (June production)
  • Model: Sany SY245H
  • Primary application: Earthmoving operations
  • Condition: Original factory specification
  • Location: Sichuan Province, China
  • Availability: Ready for immediate shipment

Ideal for contractors seeking proven earthmoving capacity with the support of Sany's established parts and service network across Asia and beyond.

SpecificationsValue
No.1074939
Tonnage (tons)24
Working weight (kg)25500
Bucket capacity (m³)1.3~1.5(1.5)
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine typeD06FRC
Rated power (kw/rpm)147/2100
Cooling modewater-cooling
Maximum torque (N.m)750/1350
Number of cylinders (PCS)6
Displacement (L)6.373
Ground specific pressure (Kpa)53.2
Rotation speed (rpm)10.6
Climbing ability (%)70
Bucket digging force (kN)175
Rod digging force (kN)120
Travel speed (km/h)5.4/3.4
Fuel Tank (L)475
Hydraulic Tank (L)277
Engine Oil changes (L)29
Total transport length (mm)10290
Total transport width (mm)3190
Total transport height (mm)3190
Full cab height (mm)3255
Minimum ground clearance (mm)470
Minimum turning radius of front working device (mm)3800
Back end turning radius (mm)3105
Onboard width (mm)3045
Total track length (mm)4445
Track gauge (mm)2590
Track plate width (mm)600
Track ground length (mm)3640
Maximum height at minimum turning radius (mm)8016
Number of sprockets (single side) (each)2
Number of wheels (single side) (each)9
Number of track plates (single side) (PCS)49
Maximum digging radius (mm)10225
Maximum digging depth (mm)6705
Maximum excavation height (mm)9745
Maximum unloading height (mm)6715
see more

Overview

No.1074939

Brand Name:

Sany

Model Number:

SY245H

Year:

2020

Location:

Sichuan China

Pub Date
