Product Description
Built in 2021, this Sany SY245H excavator delivers proven performance with the long-term support you need in a used machine. Operating at 24 tons with a robust 147 kW D06FRC engine, this Chinese-manufactured unit combines a 1.3-1.5 m³ bucket capacity with impressive reach specifications—10,225 mm maximum digging radius and 6,705 mm digging depth. Currently located in Shanghai, the SY245H represents smart investment in a brand known for accessible parts networks and strong resale value across global markets.
Key Specifications:
- Working weight: 25,500 kg with 175 kN bucket digging force
- Water-cooled 6-cylinder engine producing 750 N·m maximum torque
- Fuel capacity: 475 L for extended operation cycles
- Transport dimensions: 10,290 mm (L) × 3,190 mm (W) × 3,190 mm (H)
- 600 mm track plates providing 53.2 kPa ground pressure
Sany's widespread dealer network ensures parts availability and service support remain consistent throughout ownership. For operations requiring dependable mid-size excavation capacity backed by manufacturer longevity, this SY245H offers measurable value retention in secondary markets worldwide.
| Specifications | Value |
|---|---|
| No. | 1031768 |
| Tonnage (tons) | 24 |
| Working weight (kg) | 25500 |
| Bucket capacity (m³) | 1.3~1.5(1.5) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | D06FRC |
| Rated power (kw/rpm) | 147/2100 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 750/1350 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.373 |
| Ground specific pressure (Kpa) | 53.2 |
| Rotation speed (rpm) | 10.6 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 175 |
| Rod digging force (kN) | 120 |
| Travel speed (km/h) | 5.4/3.4 |
| Fuel Tank (L) | 475 |
| Hydraulic Tank (L) | 277 |
| Engine Oil changes (L) | 29 |
| Total transport length (mm) | 10290 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3190 |
| Full cab height (mm) | 3255 |
| Minimum ground clearance (mm) | 470 |
| Minimum turning radius of front working device (mm) | 3800 |
| Back end turning radius (mm) | 3105 |
| Onboard width (mm) | 3045 |
| Total track length (mm) | 4445 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3640 |
| Maximum height at minimum turning radius (mm) | 8016 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 9 |
| Number of track plates (single side) (PCS) | 49 |
| Maximum digging radius (mm) | 10225 |
| Maximum digging depth (mm) | 6705 |
| Maximum excavation height (mm) | 9745 |
| Maximum unloading height (mm) | 6715 |
