Product Description
This 2022 Sany SY245H hydraulic excavator represents an exceptional opportunity for contractors seeking reliable performance with minimal operational history. Located in Zhejiang, China, this machine has been maintained exclusively through authorized service channels since delivery, ensuring comprehensive documentation and adherence to manufacturer specifications.
Key highlights include:
- Low operating hours with verified maintenance records
- Complete documentation and transfer-ready paperwork
- Corporate fleet maintenance history
- Inspection-exempt condition
- Competitive pricing for immediate acquisition
The SY245H is engineered for demanding earthmoving applications, offering proven hydraulic efficiency and operator comfort. This unit's brief service life and professional upkeep make it an attractive alternative to new equipment procurement. Suitable for construction, mining, and infrastructure projects requiring a 24-ton class excavator with modern emissions compliance.
Available for immediate inspection and delivery coordination from Zhejiang province.
| Specifications | Value |
|---|---|
| No. | 1075407 |
| Tonnage (tons) | 24 |
| Working weight (kg) | 25500 |
| Bucket capacity (m³) | 1.3~1.5(1.5) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | D06FRC |
| Rated power (kw/rpm) | 147/2100 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 750/1350 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.373 |
| Ground specific pressure (Kpa) | 53.2 |
| Rotation speed (rpm) | 10.6 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 175 |
| Rod digging force (kN) | 120 |
| Travel speed (km/h) | 5.4/3.4 |
| Fuel Tank (L) | 475 |
| Hydraulic Tank (L) | 277 |
| Engine Oil changes (L) | 29 |
| Total transport length (mm) | 10290 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3190 |
| Full cab height (mm) | 3255 |
| Minimum ground clearance (mm) | 470 |
| Minimum turning radius of front working device (mm) | 3800 |
| Back end turning radius (mm) | 3105 |
| Onboard width (mm) | 3045 |
| Total track length (mm) | 4445 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3640 |
| Maximum height at minimum turning radius (mm) | 8016 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 9 |
| Number of track plates (single side) (PCS) | 49 |
| Maximum digging radius (mm) | 10225 |
| Maximum digging depth (mm) | 6705 |
| Maximum excavation height (mm) | 9745 |
| Maximum unloading height (mm) | 6715 |
