2022 Sany SY245H

1/6
Buy Sany SY245H Used Excavator / 1
Buy Sany SY245H Used Excavator / 2
Buy Sany SY245H Used Excavator / 3
Buy Sany SY245H Used Excavator / 4
Buy Sany SY245H Used Excavator / 5
Buy Sany SY245H Used Excavator / 6

Product Description

Well-maintained 2022 Sany SY245H hydraulic excavator available from Sichuan, China. This mid-size crawler excavator has accumulated 4,000 verified operating hours, indicating moderate use with substantial service life remaining. The SY245H represents Sany's commitment to reliable performance in demanding construction and earthmoving applications.

Key features of this unit include:

  • Operating weight class: approximately 24-25 tonnes
  • Fuel-efficient engine meeting modern emission standards
  • Hydraulic system optimized for productivity and control
  • Robust undercarriage designed for varied terrain conditions
  • Spacious operator cabin with enhanced visibility
  • Low actual hours with verifiable service records

This excavator is suitable for general construction, road building, material handling, and excavation projects. The machine's recent manufacturing year combined with conservative hour meter reading makes it an attractive option for contractors seeking dependable equipment at competitive value.

SpecificationsValue
No.1084321
Tonnage (tons)24
Working weight (kg)25500
Bucket capacity (m³)1.3~1.5(1.5)
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine typeD06FRC
Rated power (kw/rpm)147/2100
Cooling modewater-cooling
Maximum torque (N.m)750/1350
Number of cylinders (PCS)6
Displacement (L)6.373
Ground specific pressure (Kpa)53.2
Rotation speed (rpm)10.6
Climbing ability (%)70
Bucket digging force (kN)175
Rod digging force (kN)120
Travel speed (km/h)5.4/3.4
Fuel Tank (L)475
Hydraulic Tank (L)277
Engine Oil changes (L)29
Total transport length (mm)10290
Total transport width (mm)3190
Total transport height (mm)3190
Full cab height (mm)3255
Minimum ground clearance (mm)470
Minimum turning radius of front working device (mm)3800
Back end turning radius (mm)3105
Onboard width (mm)3045
Total track length (mm)4445
Track gauge (mm)2590
Track plate width (mm)600
Track ground length (mm)3640
Maximum height at minimum turning radius (mm)8016
Number of sprockets (single side) (each)2
Number of wheels (single side) (each)9
Number of track plates (single side) (PCS)49
Maximum digging radius (mm)10225
Maximum digging depth (mm)6705
Maximum excavation height (mm)9745
Maximum unloading height (mm)6715
