Product Description
Expand your operational capacity with this 2024 Sany SY245H excavator, currently located in Putian, Fujian. Built to China's National IV emission standards, this mid-size crawler delivers consistent performance when your primary equipment is committed or when project demands exceed single-machine capabilities. Fleet managers requiring reliable backup units will appreciate the SY245H's proven hydraulic system and robust undercarriage designed for extended duty cycles.
- Current-year manufacture ensures maximum remaining service life and warranty coverage
- 24-ton operating weight handles utility work, site prep, and material handling across diverse jobsites
- National IV compliant engine meets regional environmental regulations without performance compromise
- Immediate availability in Fujian Province reduces mobilization time for Southeast China contractors
- Standardized Sany controls simplify operator transitions between fleet units
Contractors managing multiple concurrent projects require equipment depth. This SY245H functions as your safety margin against schedule delays caused by maintenance downtime or unexpected workload surges. Factory-fresh condition with full systems i
| Specifications | Value |
|---|---|
| No. | 1013550 |
| Tonnage (tons) | 25 |
| Working weight (kg) | 25500 |
| Bucket capacity (m³) | 1.4 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Deutz |
| Rated power (kw/rpm) | 150/2100 |
| Ground specific pressure (Kpa) | 52.5 |
| Rotation speed (rpm) | 10 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 175(187) |
| Rod digging force (kN) | 120(129) |
| Travel speed (km/h) | 5.8/3.7 |
| Total transport length (mm) | 10290 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3255 |
| Full cab height (mm) | 3255 |
| Minimum ground clearance (mm) | 470 |
| Minimum turning radius of front working device (mm) | 3800 |
| Back end turning radius (mm) | 3105 |
| Onboard width (mm) | 3045 |
| Total track length (mm) | 4445 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3640 |
| Maximum height at minimum turning radius (mm) | 8016 |
| Maximum digging radius (mm) | 10225 |
| Maximum digging depth (mm) | 6705 |
| Maximum excavation height (mm) | 9745 |
| Maximum unloading height (mm) | 6715 |
| Maximum vertical digging depth (mm) | 5675 |
