Product Description
Cut your capital costs dramatically with this proven 2014 Sany SY265C excavator from Sichuan Luzhou. Delivering 26-ton performance at a fraction of new equipment pricing, this machine combines Mitsubishi D06FRC power (147 kW) with robust hydraulics that generate 175 kN bucket digging force and 120 kN arm force. Water-cooled efficiency meets field-tested reliability in this workhorse excavator.
- 26,500 kg operating weight with 1.3 m³ bucket capacity
- Maximum dig depth: 6,705 mm; reach: 10,225 mm
- 6-cylinder Mitsubishi engine (6.373L displacement, 750 N·m torque)
- 70% gradeability handles demanding terrain
- 475L fuel tank supports extended operations
- Dual-speed travel: 5.8/3.7 km/h for versatile mobility
Manufactured in China with Japanese engine technology, this SY265C offers contractor-grade capability without the new-machine premium. Inspect specifications against your project requirements—this backhoe configuration delivers immediate ROI for excavation contractors, site development firms, and heavy civil operations seeking reliable capacity.
| Specifications | Value |
|---|---|
| No. | 1019443 |
| Tonnage (tons) | 26 |
| Working weight (kg) | 26500 |
| Bucket capacity (m³) | 1.3 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Mitsubishi D06FRC |
| Rated power (kw/rpm) | 147/2100 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 750/1350 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.373 |
| Ground specific pressure (Kpa) | 52.5 |
| Rotation speed (rpm) | 10.6 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 175 |
| Rod digging force (kN) | 120 |
| Travel speed (km/h) | 5.8/3.7 |
| Fuel Tank (L) | 475 |
| Hydraulic Tank (L) | 277 |
| Engine Oil changes (L) | 29 |
| Total transport length (mm) | 10290 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3255 |
| Minimum ground clearance (mm) | 470 |
| Back end turning radius (mm) | 3105 |
| Total track length (mm) | 4635 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3830 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 9 |
| Number of track plates (single side) (PCS) | 51 |
| Maximum digging radius (mm) | 10225 |
| Maximum digging depth (mm) | 6705 |
| Maximum excavation height (mm) | 9745 |
| Maximum unloading height (mm) | 6715 |
