Product Description
Engineered for demanding jobsites, this 2014 Sany SY265C excavator delivers 26-ton performance with operator-centered design. Powered by a Mitsubishi D06FRC engine producing 147 kW at 2100 rpm, this machine combines reliable traditional power with precise hydraulic control. The water-cooled 6-cylinder configuration generates 750 N.m maximum torque, ensuring consistent performance across extended shifts.
Operators benefit from exceptional stability during operation, supported by 52.5 kPa ground pressure distribution and a 3105 mm rear turning radius. Enhanced cabin visibility allows clear sightlines to the 1.3 m³ backhoe bucket throughout the full working envelope—10225 mm maximum reach and 6705 mm digging depth. Responsive controls manage 175 kN bucket digging force and 120 kN arm force with precision.
Key operational specifications:
- Working weight: 26,500 kg with proven structural integrity
- Travel speeds: 5.8 km/h (high) / 3.7 km/h (low) for versatile mobility
- Climbing ability: 70% grade capability (35°)
- Rotation speed: 10.6 rpm for efficient cycle times
- Fuel capacity: 475 L for extended operation
Currently located in Kunming, Yunnan. Made in China with
| Specifications | Value |
|---|---|
| No. | 1049199 |
| Tonnage (tons) | 26 |
| Working weight (kg) | 26500 |
| Bucket capacity (m³) | 1.3 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Mitsubishi D06FRC |
| Rated power (kw/rpm) | 147/2100 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 750/1350 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.373 |
| Ground specific pressure (Kpa) | 52.5 |
| Rotation speed (rpm) | 10.6 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 175 |
| Rod digging force (kN) | 120 |
| Travel speed (km/h) | 5.8/3.7 |
| Fuel Tank (L) | 475 |
| Hydraulic Tank (L) | 277 |
| Engine Oil changes (L) | 29 |
| Total transport length (mm) | 10290 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3255 |
| Minimum ground clearance (mm) | 470 |
| Back end turning radius (mm) | 3105 |
| Total track length (mm) | 4635 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3830 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 9 |
| Number of track plates (single side) (PCS) | 51 |
| Maximum digging radius (mm) | 10225 |
| Maximum digging depth (mm) | 6705 |
| Maximum excavation height (mm) | 9745 |
| Maximum unloading height (mm) | 6715 |
