Commanding a 26-ton operating weight with precision, this 2016 Sany SY265C excavator delivers operator-centered performance for demanding jobsites in Guizhou. Powered by a robust Mitsubishi D06FRC engine generating 147 kW at 2100 rpm, the machine combines reliable traditional power with responsive hydraulics designed for extended shifts. Operators benefit from exceptional stability across varied terrain, supported by a 52.5 kPa ground pressure distribution and 70% climbing capability on steep grades.
Visibility and control define the working experience. With a compact 3105 mm rear swing radius and 10.6 rpm rotation speed, maneuvering in confined spaces becomes manageable without sacrificing reach—maximum digging radius extends to 10,225 mm. The water-cooled engine maintains consistent performance, while dual travel speeds (5.8/3.7 km/h) provide flexibility between transport and precision work.
- Bucket digging force: 175 kN for tough material penetration
- Maximum digging depth: 6,705 mm for deep excavation tasks
- Spacious fuel capacity: 475 L for extended operation
- 1.3 m³ backhoe bucket optimized for 26-ton class productivity
Built in China with proven Mitsubishi power, thi
| Specifications | Value |
|---|---|
| No. | 1005364 |
| Tonnage (tons) | 26 |
| Working weight (kg) | 26500 |
| Bucket capacity (m³) | 1.3 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Mitsubishi D06FRC |
| Rated power (kw/rpm) | 147/2100 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 750/1350 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.373 |
| Ground specific pressure (Kpa) | 52.5 |
| Rotation speed (rpm) | 10.6 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 175 |
| Rod digging force (kN) | 120 |
| Travel speed (km/h) | 5.8/3.7 |
| Fuel Tank (L) | 475 |
| Hydraulic Tank (L) | 277 |
| Engine Oil changes (L) | 29 |
| Total transport length (mm) | 10290 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3255 |
| Minimum ground clearance (mm) | 470 |
| Back end turning radius (mm) | 3105 |
| Total track length (mm) | 4635 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3830 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 9 |
| Number of track plates (single side) (PCS) | 51 |
| Maximum digging radius (mm) | 10225 |
| Maximum digging depth (mm) | 6705 |
| Maximum excavation height (mm) | 9745 |
| Maximum unloading height (mm) | 6715 |
