Product Description
Built for tight urban sites and precision work, this 2016 Sany SY26U mini excavator delivers immediate productivity in a compact 2-ton package. Powered by a reliable Yanmar 3TNV80F engine producing 15.2 kW at 2500 rpm, this machine tackles digging, trenching, and grading tasks with a maximum digging depth of 2820mm and a reach of 4850mm. The backhoe bucket configuration offers 0.04-0.08m³ capacity, while robust digging forces—24.3 kN bucket force and 14.2 kN arm force—handle demanding excavation work efficiently.
- Compact transport dimensions: 4285mm × 1550mm × 2430mm for easy site mobility
- Impressive 47% climbing ability navigates challenging terrain
- 290mm ground clearance protects undercarriage on rough surfaces
- Dual travel speeds (4.5/2.6 km/h) optimize productivity and precision
- 2110mm front turning radius enables work in confined spaces
- Currently located in Beijing, ready for immediate deployment
Site-ready condition means this machine arrives prepared to perform from day one. Whether you're excavating foundations, installing utilities, or performing demolition work, this proven Sany model combines Chinese manufacturing value with Japanese engine reliabili
| Specifications | Value |
|---|---|
| No. | 1036314 |
| Tonnage (tons) | 2 |
| Working weight (kg) | 2680 |
| Bucket capacity (m³) | 0.04-0.08(0.06) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar 3TNV80F |
| Rated power (kw/rpm) | 15.2/2500 |
| Maximum torque (N.m) | 63.2-67.4/1800-100 |
| Displacement (L) | 1.266 |
| Ground specific pressure (Kpa) | 25.5 |
| Rotation speed (rpm) | 10 |
| Climbing ability (%) | 47 |
| Bucket digging force (kN) | 24.3 |
| Rod digging force (kN) | 14.2 |
| Travel speed (km/h) | 4.5/2.6 |
| Fuel Tank (L) | 34 |
| Hydraulic Tank (L) | 30 |
| Engine Oil changes (L) | 3.4/1.6 |
| Total transport length (mm) | 4285 |
| Total transport width (mm) | 1550 |
| Total transport height (mm) | 2430 |
| Minimum ground clearance (mm) | 290 |
| Minimum turning radius of front working device (mm) | 2110 |
| Back end turning radius (mm) | 775 |
| Total track length (mm) | 2005 |
| Track gauge (mm) | 1250 |
| Track plate width (mm) | 300 |
| Track ground length (mm) | 1560 |
| Maximum height at minimum turning radius (mm) | 3200 |
| Number of wheels (single side) (each) | 3 |
| Maximum digging radius (mm) | 4850 |
| Maximum digging depth (mm) | 2820 |
| Maximum excavation height (mm) | 4410 |
| Maximum unloading height (mm) | 3100 |
| Maximum vertical digging depth (mm) | 2585 |
| Bulldozer lift or depth (mm) | 360/330 |
| Dodging plate width × height (mm) | 300 (height) |
