Product Description
Compact power meets proven reliability in this 2018 Sany SY26U mini excavator, offering exceptional value for contractors seeking cost-effective solutions. Operating at 2 tons with a working weight of 2,680 kg, this machine delivers impressive digging capabilities—maximum depth of 2,820 mm and radius of 4,850 mm—perfect for tight urban sites and utility work. Powered by the dependable Yanmar 3TNV80F engine producing 15.2 kW at 2,500 rpm, it combines fuel efficiency with consistent performance across demanding applications.
Key Performance Specifications:
- Bucket digging force: 24.3 kN with 0.04-0.08 m³ capacity
- Maximum excavation height: 4,410 mm; unloading height: 3,100 mm
- Compact transport dimensions: 4,285 mm (L) × 1,550 mm (W) × 2,430 mm (H)
- 47% climbing ability with 290 mm ground clearance
- 34L fuel tank and 30L hydraulic tank for extended operations
Currently located in Hunan, China, this 2018 model represents a smart alternative to new equipment purchases—delivering professional-grade performance at a fraction of replacement cost. Ideal for landscaping, utility installation, and light construction projects requiring maneuverability without
| Specifications | Value |
|---|---|
| No. | 1045643 |
| Tonnage (tons) | 2 |
| Working weight (kg) | 2680 |
| Bucket capacity (m³) | 0.04-0.08(0.06) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar 3TNV80F |
| Rated power (kw/rpm) | 15.2/2500 |
| Maximum torque (N.m) | 63.2-67.4/1800-100 |
| Displacement (L) | 1.266 |
| Ground specific pressure (Kpa) | 25.5 |
| Rotation speed (rpm) | 10 |
| Climbing ability (%) | 47 |
| Bucket digging force (kN) | 24.3 |
| Rod digging force (kN) | 14.2 |
| Travel speed (km/h) | 4.5/2.6 |
| Fuel Tank (L) | 34 |
| Hydraulic Tank (L) | 30 |
| Engine Oil changes (L) | 3.4/1.6 |
| Total transport length (mm) | 4285 |
| Total transport width (mm) | 1550 |
| Total transport height (mm) | 2430 |
| Minimum ground clearance (mm) | 290 |
| Minimum turning radius of front working device (mm) | 2110 |
| Back end turning radius (mm) | 775 |
| Total track length (mm) | 2005 |
| Track gauge (mm) | 1250 |
| Track plate width (mm) | 300 |
| Track ground length (mm) | 1560 |
| Maximum height at minimum turning radius (mm) | 3200 |
| Number of wheels (single side) (each) | 3 |
| Maximum digging radius (mm) | 4850 |
| Maximum digging depth (mm) | 2820 |
| Maximum excavation height (mm) | 4410 |
| Maximum unloading height (mm) | 3100 |
| Maximum vertical digging depth (mm) | 2585 |
| Bulldozer lift or depth (mm) | 360/330 |
| Dodging plate width × height (mm) | 300 (height) |
