Product Description
Engineered for precision in confined jobsites, this 2024 Sany SY26U mini excavator delivers robust performance through proven Japanese power technology. Equipped with a Yanmar 3TNV80F engine generating 15.2 kW at 2500 rpm and maximum torque of 67.4 N·m, this 2.68-ton machine combines compact dimensions with impressive hydraulic force—24.3 kN bucket digging force and 14.2 kN arm digging force ensure efficient material handling across diverse applications.
Operating specifications demonstrate Sany's engineering focus on versatility and capability. With a maximum digging depth of 2,820 mm and digging radius extending to 4,850 mm, the SY26U accesses tight working areas while maintaining a minimal turning radius of 2,110 mm. The 0.06 m³ bucket capacity balances productivity with maneuverability, while 47% gradeability and 290 mm ground clearance enable operation on challenging terrain.
Currently located in Huizhou, Guangdong, this China-manufactured unit features dual-speed travel (4.5/2.6 km/h), 34-liter fuel capacity, and a compact transport profile (4,285 × 1,550 × 2,430 mm). Backed by Sany's reputation for durable construction machinery, the SY26U represents reliable value for contractors requiring dependable micro-ex
| Specifications | Value |
|---|---|
| No. | 1039307 |
| Tonnage (tons) | 2 |
| Working weight (kg) | 2680 |
| Bucket capacity (m³) | 0.04-0.08(0.06) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar 3TNV80F |
| Rated power (kw/rpm) | 15.2/2500 |
| Maximum torque (N.m) | 63.2-67.4/1800-100 |
| Displacement (L) | 1.266 |
| Ground specific pressure (Kpa) | 25.5 |
| Rotation speed (rpm) | 10 |
| Climbing ability (%) | 47 |
| Bucket digging force (kN) | 24.3 |
| Rod digging force (kN) | 14.2 |
| Travel speed (km/h) | 4.5/2.6 |
| Fuel Tank (L) | 34 |
| Hydraulic Tank (L) | 30 |
| Engine Oil changes (L) | 3.4/1.6 |
| Total transport length (mm) | 4285 |
| Total transport width (mm) | 1550 |
| Total transport height (mm) | 2430 |
| Minimum ground clearance (mm) | 290 |
| Minimum turning radius of front working device (mm) | 2110 |
| Back end turning radius (mm) | 775 |
| Total track length (mm) | 2005 |
| Track gauge (mm) | 1250 |
| Track plate width (mm) | 300 |
| Track ground length (mm) | 1560 |
| Maximum height at minimum turning radius (mm) | 3200 |
| Number of wheels (single side) (each) | 3 |
| Maximum digging radius (mm) | 4850 |
| Maximum digging depth (mm) | 2820 |
| Maximum excavation height (mm) | 4410 |
| Maximum unloading height (mm) | 3100 |
| Maximum vertical digging depth (mm) | 2585 |
| Bulldozer lift or depth (mm) | 360/330 |
| Dodging plate width × height (mm) | 300 (height) |
