Product Description
Expand your fleet capacity with this 2016 Sany SY285C-8 hydraulic excavator, currently positioned in Luzhou, Sichuan. Built for contractors managing multiple jobsites simultaneously, this 28-ton machine delivers consistent performance as a backup unit or dedicated secondary excavator. Powered by a 6-cylinder Isuzu engine producing 184 kW at 2100 rpm, it maintains productivity during peak demand periods without compromising your primary equipment schedules.
- 28,500 kg operating weight with 1.35 m³ backhoe bucket capacity
- Dual hydraulic pumps (2 × 280 l/min) supporting responsive multi-function operation
- Maximum digging reach of 10,620 mm and depth of 7,090 mm for versatile applications
- 193 kN bucket digging force handles compacted materials efficiently
- 600 mm track plates and 3,700 mm ground contact length ensure stability on varied terrain
- Water-cooled Isuzu engine designed for extended duty cycles
Manufactured in Kunshan, Jiangsu Province, this crawler excavator integrates seamlessly into existing Sany fleets or serves as cross-brand reinforcement during equipment rotations and scheduled maintenance windows.
| Specifications | Value |
|---|---|
| No. | 1025731 |
| Tonnage (tons) | 28 |
| Working weight (kg) | 28500 |
| Bucket capacity (m³) | 1.35 |
| Country of origin | Kunshan in Jiangsu Province |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Isuzu |
| Rated power (kw/rpm) | 184(2100) |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Ground specific pressure (Kpa) | 62 |
| Rotation speed (rpm) | 11.5 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 193 |
| Rod digging force (kN) | 163 |
| Travel speed (km/h) | 3.5/5.5 |
| Main overflow set pressure (Mpa) | 34.3 |
| Maximum flow of main pump (l/min) | 2 x 280 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 27.5 |
| Control Hydraulic Circuit (Mpa) | 3.9 |
| Hydraulic crushing pipeline is standard | no |
| Total transport length (mm) | 10560 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3430 |
| Full cab height (mm) | 3096 |
| Minimum ground clearance (mm) | 500 |
| Back end turning radius (mm) | 3250 |
| Total track length (mm) | 4650 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2980 |
| Track ground length (mm) | 3700 |
| Maximum digging radius (mm) | 10620 |
| Maximum digging depth (mm) | 7090 |
| Maximum excavation height (mm) | 9948 |
| Maximum unloading height (mm) | 6850 |
| Maximum vertical digging depth (mm) | 6010 |
| Bulldozer lift or depth (mm) | There is no |
