Product Description
Discover the reliability and efficiency of the 2020 Sany SY35U-10, a used heavy machine available for purchase. This 35-ton excavator is located in Shandong, China, and has been meticulously maintained by its single owner. Priced at 300,000 RMB, it represents a cost-effective solution for your construction or excavation needs. The SY35U-10 is known for its robust performance and durability, making it an excellent addition to any fleet. Inspections can be arranged in Xicheng, ensuring you have the opportunity to assess the machine's condition firsthand.
- Year: 2020
- Brand: Sany
- Model: SY35U-10
- Location: Shandong, China
- Price: 300,000 RMB
- Single Owner
| Specifications | Value |
|---|---|
| No. | 1100881 |
| Tonnage (tons) | 3 |
| Working weight (kg) | 3500 |
| Bucket capacity (m³) | 0.12 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | 3TNV88 Stages3A EPA int4 |
| Rated power (kw/rpm) | 20.4/2200 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 107/1300 |
| Displacement (L) | 1.642 |
| Ground specific pressure (Kpa) | 32 |
| Rotation speed (rpm) | 9 |
| Climbing ability (%) | 58 |
| Bucket digging force (kN) | 30.4 |
| Rod digging force (kN) | 18.2 |
| Travel speed (km/h) | 4.4 /2.4 |
| Fuel Tank (L) | 40 |
| Hydraulic Tank (L) | 40 |
| Engine Oil changes (L) | 6 |
| Total transport length (mm) | 4915 |
| Total transport width (mm) | 1720 |
| Total transport height (mm) | 2515 |
| Minimum ground clearance (mm) | 295 |
| Minimum turning radius of front working device (mm) | 2475 |
| Back end turning radius (mm) | 860 |
| Total track length (mm) | 2155 |
| Track gauge (mm) | 1420 |
| Track plate width (mm) | 300 |
| Track ground length (mm) | 1670 |
| Maximum height at minimum turning radius (mm) | 3685 |
| Number of wheels (single side) (each) | 4 |
| Maximum digging radius (mm) | 5465 |
| Maximum digging depth (mm) | 3105 |
| Maximum excavation height (mm) | 4855 |
| Maximum unloading height (mm) | 3460 |
| Maximum vertical digging depth (mm) | 2700 |
| Bulldozer lift or depth (mm) | 375/370 |
| Dodging plate width × height (mm) | Height: 350 |
