Product Description
Discover the 2020 Sany SY35U-10, a robust and reliable mini excavator, available for immediate purchase from Shandong, China. This machine, with an operating weight of 3.5 tons, has been well-maintained by a single owner in the West City area of Dongying. Designed for efficiency and durability, the SY35U-10 is ideal for construction, landscaping, and utility work. Sany, known for its commitment to quality and innovation, ensures that this model delivers powerful performance and easy maneuverability, making it a valuable addition to any fleet.
- Year: 2020
- Brand: Sany
- Model: SY35U-10
- Operating Weight: 3.5 tons
- Location: Shandong, China
- Condition: Used, single owner
| Specifications | Value |
|---|---|
| No. | 1100882 |
| Tonnage (tons) | 3 |
| Working weight (kg) | 3500 |
| Bucket capacity (m³) | 0.12 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | 3TNV88 Stages3A EPA int4 |
| Rated power (kw/rpm) | 20.4/2200 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 107/1300 |
| Displacement (L) | 1.642 |
| Ground specific pressure (Kpa) | 32 |
| Rotation speed (rpm) | 9 |
| Climbing ability (%) | 58 |
| Bucket digging force (kN) | 30.4 |
| Rod digging force (kN) | 18.2 |
| Travel speed (km/h) | 4.4 /2.4 |
| Fuel Tank (L) | 40 |
| Hydraulic Tank (L) | 40 |
| Engine Oil changes (L) | 6 |
| Total transport length (mm) | 4915 |
| Total transport width (mm) | 1720 |
| Total transport height (mm) | 2515 |
| Minimum ground clearance (mm) | 295 |
| Minimum turning radius of front working device (mm) | 2475 |
| Back end turning radius (mm) | 860 |
| Total track length (mm) | 2155 |
| Track gauge (mm) | 1420 |
| Track plate width (mm) | 300 |
| Track ground length (mm) | 1670 |
| Maximum height at minimum turning radius (mm) | 3685 |
| Number of wheels (single side) (each) | 4 |
| Maximum digging radius (mm) | 5465 |
| Maximum digging depth (mm) | 3105 |
| Maximum excavation height (mm) | 4855 |
| Maximum unloading height (mm) | 3460 |
| Maximum vertical digging depth (mm) | 2700 |
| Bulldozer lift or depth (mm) | 375/370 |
| Dodging plate width × height (mm) | Height: 350 |
