HOME>>Sany>>Sany SY365C-8

2013 Sany SY365C-8

1/8
Buy Sany SY365C-8 Used Excavator / 1
Buy Sany SY365C-8 Used Excavator / 2
Buy Sany SY365C-8 Used Excavator / 3
Buy Sany SY365C-8 Used Excavator / 4
Buy Sany SY365C-8 Used Excavator / 5
Buy Sany SY365C-8 Used Excavator / 6
Buy Sany SY365C-8 Used Excavator / 7
Buy Sany SY365C-8 Used Excavator / 8

Product Description

Built for heavy-cycle work, this 2013 Sany SY365C-8 is a proven 36-ton excavator ready to slot directly into an active fleet. Powered by an Isuzu engine rated at 190.5 kW, it delivers a bucket digging force of 220 kN and a 1.6 m³ capacity — capable of keeping pace with the most demanding earthmoving schedules. Currently located in Guangdong, China, and available for prompt international shipping.

  • Engine: Isuzu, 190.5 kW / 2000 rpm
  • Operating Weight: 34,100 kg
  • Bucket Capacity: 1.6 m³ (backhoe)
  • Bucket Digging Force: 220 kN
  • Max Digging Depth: 7,040 mm
  • Max Digging Radius: 10,615 mm
  • Travel Speed: 5.5 / 3.5 km/h
  • Climbing Ability: 70% / 35°
  • Track Plate Width: 600 mm
  • Location: Guangdong, China

For contractors running tight schedules, a reliable backup unit reduces costly downtime. With solid undercarriage dimensions, a 550 mm ground clearance, and a 70% gradeability rating, this machine handles site conditions that sideline lesser equipment.

SpecificationsValue
No.1077173
Tonnage (tons)36
Working weight (kg)34100
Bucket capacity (m³)1.6
Country of originKunshan in Jiangsu Province
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine typeIsuzu
Rated power (kw/rpm)190.5/2000
Ground specific pressure (Kpa)59.9
Rotation speed (rpm)9.5
Climbing ability (%)70/35 °
Bucket digging force (kN)220
Rod digging force (kN)180
Travel speed (km/h)5.5/3.5
Total transport length (mm)11015
Total transport width (mm)3190
Total transport height (mm)3315
Full cab height (mm)3025
Minimum ground clearance (mm)550
Minimum turning radius of front working device (mm)4370
Back end turning radius (mm)3300
Total track length (mm)5050
Track gauge (mm)2590
Track plate width (mm)600
Total track width (mm)3190
Track ground length (mm)4140
Maximum digging radius (mm)10615
Maximum digging depth (mm)7040
Maximum excavation height (mm)9810
Maximum unloading height (mm)7140
Maximum vertical digging depth (mm)6280
Bulldozer lift or depth (mm)There is no
Dodging plate width × height (mm)There is no
see more

Overview

No.1077173

Brand Name:

Sany

Model Number:

SY365C-8

Year:

2013

Location:

Guangdong China

Pub Date
