Product Description
Engineered with precision in Kunshan, this 2019 Sany SY365C-8 delivers 36-ton performance through proven hydraulic architecture and reliable Isuzu power. Rated at 190.5 kW (2000 rpm), the engine drives exceptional digging forces of 220 kN (bucket) and 180 kN (arm), enabling maximum excavation depth of 7,040 mm and reach extending to 10,615 mm. Operating weight of 34,100 kg provides stable platform dynamics while maintaining ground pressure at just 59.9 kPa across 600 mm track plates.
- 1.6 m³ backhoe bucket capacity for high-volume material handling
- Superior climbing ability: 70% grade (35°) for challenging terrain
- Fast cycle times with 9.5 rpm rotation speed
- Compact transport dimensions: 11,015 × 3,190 × 3,315 mm
- 4,140 mm track ground contact for enhanced stability
- Dual travel speeds (5.5/3.5 km/h) optimize productivity
Currently located in Shandong, this SY365C-8 represents Sany's commitment to hydraulic efficiency and structural durability. Technical documentation and inspection reports available upon request.
| Specifications | Value |
|---|---|
| No. | 1029659 |
| Tonnage (tons) | 36 |
| Working weight (kg) | 34100 |
| Bucket capacity (m³) | 1.6 |
| Country of origin | Kunshan in Jiangsu Province |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Isuzu |
| Rated power (kw/rpm) | 190.5/2000 |
| Ground specific pressure (Kpa) | 59.9 |
| Rotation speed (rpm) | 9.5 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 220 |
| Rod digging force (kN) | 180 |
| Travel speed (km/h) | 5.5/3.5 |
| Total transport length (mm) | 11015 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3315 |
| Full cab height (mm) | 3025 |
| Minimum ground clearance (mm) | 550 |
| Minimum turning radius of front working device (mm) | 4370 |
| Back end turning radius (mm) | 3300 |
| Total track length (mm) | 5050 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3190 |
| Track ground length (mm) | 4140 |
| Maximum digging radius (mm) | 10615 |
| Maximum digging depth (mm) | 7040 |
| Maximum excavation height (mm) | 9810 |
| Maximum unloading height (mm) | 7140 |
| Maximum vertical digging depth (mm) | 6280 |
| Bulldozer lift or depth (mm) | There is no |
| Dodging plate width × height (mm) | There is no |
