Product Description
Engineered with precision in Kunshan, Jiangsu Province, this 2021 Sany SY365C-8 delivers robust performance through its Isuzu engine producing 190.5 kW at 2000 rpm. Operating at 36 tons with a working weight of 34,100 kg, this excavator combines substantial digging force with operational efficiency. Bucket digging force reaches 220 kN while rod digging force achieves 180 kN, enabling demanding excavation tasks across various jobsite conditions.
- Maximum digging reach: 10,615 mm with depth capability of 7,040 mm
- 1.6 m³ backhoe bucket capacity for high-volume material handling
- Rotation speed of 9.5 rpm ensures swift positioning and cycle times
- Ground pressure of just 59.9 kPa minimizes surface impact
- Climbing ability rated at 70% (35°) for challenging terrain
- Travel speeds of 5.5/3.5 km/h optimize site mobility
Currently located in Maoming, Guangdong, this machine represents Sany's commitment to hydraulic efficiency and structural durability. Transport dimensions of 11,015 × 3,190 × 3,315 mm facilitate logistics planning for international deployment.
| Specifications | Value |
|---|---|
| No. | 1027846 |
| Tonnage (tons) | 36 |
| Working weight (kg) | 34100 |
| Bucket capacity (m³) | 1.6 |
| Country of origin | Kunshan in Jiangsu Province |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Isuzu |
| Rated power (kw/rpm) | 190.5/2000 |
| Ground specific pressure (Kpa) | 59.9 |
| Rotation speed (rpm) | 9.5 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 220 |
| Rod digging force (kN) | 180 |
| Travel speed (km/h) | 5.5/3.5 |
| Total transport length (mm) | 11015 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3315 |
| Full cab height (mm) | 3025 |
| Minimum ground clearance (mm) | 550 |
| Minimum turning radius of front working device (mm) | 4370 |
| Back end turning radius (mm) | 3300 |
| Total track length (mm) | 5050 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3190 |
| Track ground length (mm) | 4140 |
| Maximum digging radius (mm) | 10615 |
| Maximum digging depth (mm) | 7040 |
| Maximum excavation height (mm) | 9810 |
| Maximum unloading height (mm) | 7140 |
| Maximum vertical digging depth (mm) | 6280 |
| Bulldozer lift or depth (mm) | There is no |
| Dodging plate width × height (mm) | There is no |
