Product Description
With a robust 36-ton capacity and a powerful Isuzu engine, the Sany SY365H-9 excavator from 2014 stands as a reliable choice for demanding construction projects. Featuring a 1.6 m³ rock bucket and a traditional power system, this machine ensures efficient performance and durability. Originating from Shanghai, Sany is known for its strong resale value and wide availability of parts, making it a safe investment in the used equipment market.
- Rated power: 190.5 kW at 2000 rpm
- Bucket digging force: 235 kN
- Travel speed: 5.5/3.5 km/h
- Total transport dimensions: 11360 mm (length) x 3190 mm (width) x 3550 mm (height)
- Maximum digging depth: 7040 mm
| Specifications | Value |
|---|---|
| No. | 1004466 |
| Tonnage (tons) | 36 |
| Working weight (kg) | 35000 |
| Bucket capacity (m³) | 1.6(Rock) |
| Country of origin | Shanghai |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Isuzu |
| Rated power (kw/rpm) | 190.5/2000 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6-cylinder |
| Working form | Four stroke six cylinder turbocharged intercooled direct injection engine |
| Ground specific pressure (Kpa) | 63 |
| Rotation speed (rpm) | 9.5 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 235 |
| Rod digging force (kN) | 180 |
| Travel speed (km/h) | 5.5/3.5 |
| Total transport length (mm) | 11360 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3550 |
| Full cab height (mm) | 3320 |
| Minimum ground clearance (mm) | 550 |
| Minimum turning radius of front working device (mm) | 4330 |
| Back end turning radius (mm) | 3380 |
| Onboard width (mm) | 3150 |
| Total track length (mm) | 5065 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 (800/700 optional) |
| Total track width (mm) | 3190 |
| Track ground length (mm) | 4140 |
| Maximum height at minimum turning radius (mm) | 8600 |
| Maximum digging radius (mm) | 10610 |
| Maximum digging depth (mm) | 7040 |
| Maximum excavation height (mm) | 9900 |
| Maximum unloading height (mm) | 6930 |
| Maximum vertical digging depth (mm) | 5180 |
| Bulldozer lift or depth (mm) | There is no |
| Dodging plate width × height (mm) | There is no |
