Product Description
Delivering exceptional value without compromising performance, this 2016 Sany SY375H excavator represents a smart alternative to new equipment pricing. Operating at 37 tons with a robust 212kW Isuzu GH-6HK1XKSC engine, this machine combines proven reliability with impressive digging capabilities—235kN bucket force and 10,750mm maximum reach handle demanding excavation tasks with efficiency.
Key specifications include:
- 37,500kg working weight with 1.9m³ bucket capacity for optimal productivity
- Water-cooled 6-cylinder turbocharged engine (7.79L displacement, 1080N·m torque)
- Superior reach: 7,155mm digging depth, 9,920mm excavation height
- 540L fuel tank supports extended operation cycles
- 70% climbing ability and 8.8rpm rotation speed for versatile job site performance
Currently located in Luzhou, Sichuan, this backhoe-equipped excavator offers contractors and fleet managers substantial cost savings compared to new models while maintaining the performance standards required for heavy construction, mining, and infrastructure projects. Invest strategically in proven machinery that delivers results.
| Specifications | Value |
|---|---|
| No. | 1024492 |
| Tonnage (tons) | 37 |
| Working weight (kg) | 37500 |
| Bucket capacity (m³) | 1.7-2.4 (1.9) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | GH-6HK1XKSC |
| Rated power (kw/rpm) | 212/2000 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 1080/1500 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 7.79 |
| Working form | Direct injection, 6 cylinders, 4 strokes, turbocharged, water cooled |
| Ground specific pressure (Kpa) | 68.8 |
| Rotation speed (rpm) | 8.8 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 235 |
| Rod digging force (kN) | 210 |
| Travel speed (km/h) | 5.5/3.5 |
| Fuel Tank (L) | 540 |
| Engine Oil changes (L) | 36 |
| Total transport length (mm) | 11425 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3825 |
| Full cab height (mm) | 3440 |
| Minimum ground clearance (mm) | 550 |
| Minimum turning radius of front working device (mm) | 4390 |
| Back end turning radius (mm) | 3610 |
| Onboard width (mm) | 3230 |
| Total track length (mm) | 5100 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 4140 |
| Maximum height at minimum turning radius (mm) | 8930 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 9 |
| Number of track plates (single side) (PCS) | 49 |
| Maximum digging radius (mm) | 10750 |
| Maximum digging depth (mm) | 7155 |
| Maximum excavation height (mm) | 9920 |
| Maximum unloading height (mm) | 7010 |
| Maximum vertical digging depth (mm) | 5125 |
