2019 Sany SY375H

1/5
Buy Sany SY375H Used Excavator / 1
Buy Sany SY375H Used Excavator / 2
Buy Sany SY375H Used Excavator / 3
Buy Sany SY375H Used Excavator / 4
Buy Sany SY375H Used Excavator / 5

Product Description

Engineered for relentless performance, this 2019 Sany SY375H medium excavator delivers proven reliability across demanding jobsites. With 37 tons of working weight and a robust 212kW GH-6HK1XKSC engine generating 1080 N·m of maximum torque, this machine powers through excavation tasks with exceptional efficiency. Currently located in Putian, Fujian, this workhorse combines Sany's renowned build quality with practical specifications that maximize productivity.

  • Power & Performance: 212kW rated power at 2000 rpm with water-cooled 6-cylinder turbocharged engine
  • Digging Capabilities: 235kN bucket digging force, 10,750mm maximum reach, 7,155mm maximum depth
  • Operational Efficiency: 1.7-2.4m³ bucket capacity, 8.8 rpm rotation speed, 70% climbing ability
  • Built to Last: Heavy-duty undercarriage with 49 track plates per side, 540L fuel capacity for extended operation
  • Versatile Dimensions: 3,190mm transport width, 550mm ground clearance for challenging terrain navigation

Backed by four years of proven field performance, this SY375H represents exceptional value for contractors seeking dep

SpecificationsValue
No.1037297
Tonnage (tons)37
Working weight (kg)37500
Bucket capacity (m³)1.7-2.4 (1.9)
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine typeGH-6HK1XKSC
Rated power (kw/rpm)212/2000
Cooling modewater-cooling
Maximum torque (N.m)1080/1500
Number of cylinders (PCS)6
Displacement (L)7.79
Working formDirect injection, 6 cylinders, 4 strokes, turbocharged, water cooled
Ground specific pressure (Kpa)68.8
Rotation speed (rpm)8.8
Climbing ability (%)70
Bucket digging force (kN)235
Rod digging force (kN)210
Travel speed (km/h)5.5/3.5
Fuel Tank (L)540
Engine Oil changes (L)36
Total transport length (mm)11425
Total transport width (mm)3190
Total transport height (mm)3825
Full cab height (mm)3440
Minimum ground clearance (mm)550
Minimum turning radius of front working device (mm)4390
Back end turning radius (mm)3610
Onboard width (mm)3230
Total track length (mm)5100
Track gauge (mm)2590
Track plate width (mm)600
Track ground length (mm)4140
Maximum height at minimum turning radius (mm)8930
Number of sprockets (single side) (each)2
Number of wheels (single side) (each)9
Number of track plates (single side) (PCS)49
Maximum digging radius (mm)10750
Maximum digging depth (mm)7155
Maximum excavation height (mm)9920
Maximum unloading height (mm)7010
Maximum vertical digging depth (mm)5125
see more

Overview

No.1037297

Brand Name:

Sany

Model Number:

SY375H

Year:

2019

Location:

Fujian China

Pub Date
