Product Description
Engineered for precision and daily productivity, this 2020 Sany SY375H delivers 37-ton performance with operator-first design. Powered by a 212kW GH-6HK1XKSC engine generating 1080 N·m of torque, this excavator combines 235kN bucket digging force with refined hydraulic responsiveness for demanding jobsites. Operators benefit from enhanced cabin visibility across the 10,750mm maximum digging radius, while the 8.8 rpm rotation speed and 68.8 kPa ground pressure ensure stable positioning on varied terrain.
- Operator Comfort: Spacious cab with 3,440mm height and panoramic sightlines to all four corners
- Digging Performance: 1.9m³ bucket capacity, 7,155mm maximum depth, 210kN arm force
- Stability & Control: 4,140mm track ground contact, 600mm shoe width, 70% grading capability
- Power System: Water-cooled 6-cylinder turbocharged engine, 540L fuel capacity
- Maneuverability: 3,610mm rear swing radius, dual travel speeds (5.5/3.5 km/h)
Currently located in Hunan, China, this machine represents proven Sany hydraulic technology with low specific ground pressure for reduced surface damage. Ready for in
| Specifications | Value |
|---|---|
| No. | 1043562 |
| Tonnage (tons) | 37 |
| Working weight (kg) | 37500 |
| Bucket capacity (m³) | 1.7-2.4 (1.9) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | GH-6HK1XKSC |
| Rated power (kw/rpm) | 212/2000 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 1080/1500 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 7.79 |
| Working form | Direct injection, 6 cylinders, 4 strokes, turbocharged, water cooled |
| Ground specific pressure (Kpa) | 68.8 |
| Rotation speed (rpm) | 8.8 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 235 |
| Rod digging force (kN) | 210 |
| Travel speed (km/h) | 5.5/3.5 |
| Fuel Tank (L) | 540 |
| Engine Oil changes (L) | 36 |
| Total transport length (mm) | 11425 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3825 |
| Full cab height (mm) | 3440 |
| Minimum ground clearance (mm) | 550 |
| Minimum turning radius of front working device (mm) | 4390 |
| Back end turning radius (mm) | 3610 |
| Onboard width (mm) | 3230 |
| Total track length (mm) | 5100 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 4140 |
| Maximum height at minimum turning radius (mm) | 8930 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 9 |
| Number of track plates (single side) (PCS) | 49 |
| Maximum digging radius (mm) | 10750 |
| Maximum digging depth (mm) | 7155 |
| Maximum excavation height (mm) | 9920 |
| Maximum unloading height (mm) | 7010 |
| Maximum vertical digging depth (mm) | 5125 |
