2020 Sany SY375H

1/5
Buy Sany SY375H Used Excavator / 1
Buy Sany SY375H Used Excavator / 2
Buy Sany SY375H Used Excavator / 3
Buy Sany SY375H Used Excavator / 4
Buy Sany SY375H Used Excavator / 5

Product Description

Built for high-output earthmoving and heavy excavation, this 2020 Sany SY375H crawler excavator delivers 37 tons of working weight and 212 kW of diesel power to handle demanding site conditions. Equipped with a proven GH-6HK1XKSC 6-cylinder engine producing 1080 N·m of torque, this machine cuts through compacted soil, rock, and demolition debris without hesitation. The 1.9 m³ backhoe bucket generates 235 kN of digging force with a maximum reach of 10.75 meters and depth capacity of 7.15 meters—ideal for foundation work, trenching, and bulk excavation projects.

Key performance specifications include:

  • 37,500 kg operating weight with 68.8 kPa ground pressure for stability on varied terrain
  • 8.8 rpm swing speed and 70% grading ability for efficient positioning
  • 540-liter fuel tank supporting extended shift operations
  • Water-cooled turbocharged engine with direct injection for reliable performance
  • 3,190 mm transport width and 600 mm track plates for job site mobility

Currently located in Sichuan, China, this SY375H is inspection-ready and available for immediate deployment on construction, mining, or demolition sites worldwide.

SpecificationsValue
No.1044084
Tonnage (tons)37
Working weight (kg)37500
Bucket capacity (m³)1.7-2.4 (1.9)
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine typeGH-6HK1XKSC
Rated power (kw/rpm)212/2000
Cooling modewater-cooling
Maximum torque (N.m)1080/1500
Number of cylinders (PCS)6
Displacement (L)7.79
Working formDirect injection, 6 cylinders, 4 strokes, turbocharged, water cooled
Ground specific pressure (Kpa)68.8
Rotation speed (rpm)8.8
Climbing ability (%)70
Bucket digging force (kN)235
Rod digging force (kN)210
Travel speed (km/h)5.5/3.5
Fuel Tank (L)540
Engine Oil changes (L)36
Total transport length (mm)11425
Total transport width (mm)3190
Total transport height (mm)3825
Full cab height (mm)3440
Minimum ground clearance (mm)550
Minimum turning radius of front working device (mm)4390
Back end turning radius (mm)3610
Onboard width (mm)3230
Total track length (mm)5100
Track gauge (mm)2590
Track plate width (mm)600
Track ground length (mm)4140
Maximum height at minimum turning radius (mm)8930
Number of sprockets (single side) (each)2
Number of wheels (single side) (each)9
Number of track plates (single side) (PCS)49
Maximum digging radius (mm)10750
Maximum digging depth (mm)7155
Maximum excavation height (mm)9920
Maximum unloading height (mm)7010
Maximum vertical digging depth (mm)5125
see more

Overview

No.1044084

Brand Name:

Sany

Model Number:

SY375H

Year:

2020

Location:

Sichuan China

Pub Date
