2020 Sany SY375H

1/9
Buy Sany SY375H Used Excavator / 1
Buy Sany SY375H Used Excavator / 2
Buy Sany SY375H Used Excavator / 3
Buy Sany SY375H Used Excavator / 4
Buy Sany SY375H Used Excavator / 5
Buy Sany SY375H Used Excavator / 6
Buy Sany SY375H Used Excavator / 7
Buy Sany SY375H Used Excavator / 8
Buy Sany SY375H Used Excavator / 9

Product Description

Built for demanding excavation work, the Sany SY375H delivers 37-tonne performance backed by a 6-cylinder, 7.79L turbocharged water-cooled engine producing 212 kW at 2000 rpm and 1080 N·m of peak torque. Direct injection and 4-stroke combustion keep fuel consumption in check across extended shifts, supported by a 540-liter tank.

Engineered for precision and reach, this 2020 model offers a maximum digging radius of 10,750 mm, digging depth of 7,155 mm, and bucket digging force of 235 kN — figures that position it firmly in the heavy-duty tier. A 1.9 m³ backhoe bucket handles high-volume material movement with consistent cycle efficiency.

  • Working weight: 37,500 kg | Ground pressure: 68.8 kPa
  • Rated power: 212 kW / 2000 rpm | Max torque: 1080 N·m / 1500 rpm
  • Bucket digging force: 235 kN | Arm digging force: 210 kN
  • Max digging depth: 7,155 mm | Max reach: 10,750 mm
  • Travel speed: 5.5 / 3.5 km/h | Climbing ability: 70%
  • Track plate width: 600 mm | Transport dimensions: 11,425 × 3,190 × 3,825 mm
  • Location: Zhejiang, China | Available for global export
SpecificationsValue
No.1071148
Tonnage (tons)37
Working weight (kg)37500
Bucket capacity (m³)1.7-2.4 (1.9)
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine typeGH-6HK1XKSC
Rated power (kw/rpm)212/2000
Cooling modewater-cooling
Maximum torque (N.m)1080/1500
Number of cylinders (PCS)6
Displacement (L)7.79
Working formDirect injection, 6 cylinders, 4 strokes, turbocharged, water cooled
Ground specific pressure (Kpa)68.8
Rotation speed (rpm)8.8
Climbing ability (%)70
Bucket digging force (kN)235
Rod digging force (kN)210
Travel speed (km/h)5.5/3.5
Fuel Tank (L)540
Engine Oil changes (L)36
Total transport length (mm)11425
Total transport width (mm)3190
Total transport height (mm)3825
Full cab height (mm)3440
Minimum ground clearance (mm)550
Minimum turning radius of front working device (mm)4390
Back end turning radius (mm)3610
Onboard width (mm)3230
Total track length (mm)5100
Track gauge (mm)2590
Track plate width (mm)600
Track ground length (mm)4140
Maximum height at minimum turning radius (mm)8930
Number of sprockets (single side) (each)2
Number of wheels (single side) (each)9
Number of track plates (single side) (PCS)49
Maximum digging radius (mm)10750
Maximum digging depth (mm)7155
Maximum excavation height (mm)9920
Maximum unloading height (mm)7010
Maximum vertical digging depth (mm)5125
see more

Overview

No.1071148

Brand Name:

Sany

Model Number:

SY375H

Year:

2020

Location:

Zhejiang China

Pub Date
