2021 Sany SY375H

1/7
Buy Sany SY375H Used Excavator / 1
Buy Sany SY375H Used Excavator / 2
Buy Sany SY375H Used Excavator / 3
Buy Sany SY375H Used Excavator / 4
Buy Sany SY375H Used Excavator / 5
Buy Sany SY375H Used Excavator / 6
Buy Sany SY375H Used Excavator / 7

Product Description

Engineered for relentless performance, this 2021 Sany SY375H excavator delivers proven reliability across demanding jobsites. Operating at 37 tons with a robust 212kW GH-6HK1XKSC engine, this machine combines substantial digging force with exceptional fuel efficiency. Its 235kN bucket digging force and 210kN arm digging force tackle the toughest materials, while the 1.9m³ bucket capacity maximizes productivity on every cycle.

Built to last through extended operations, this workhorse features a water-cooled, turbocharged 6-cylinder engine producing 1080 N.m of torque. With a maximum digging reach of 10,750mm and depth of 7,155mm, it handles large-scale excavation with precision. Currently located in Maoming, Guangdong, this proven performer maintains its structural integrity and operational excellence.

  • 37-ton working weight with 540L fuel capacity for extended shifts
  • Advanced hydraulic system delivering consistent power distribution
  • 70% climbing ability and 8.8 RPM rotation speed for versatile positioning
  • Comprehensive transport dimensions: 11,425mm × 3,190mm × 3,825mm
  • Durable undercarriage with 49 track plates per side
SpecificationsValue
No.1049242
Tonnage (tons)37
Working weight (kg)37500
Bucket capacity (m³)1.7-2.4 (1.9)
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine typeGH-6HK1XKSC
Rated power (kw/rpm)212/2000
Cooling modewater-cooling
Maximum torque (N.m)1080/1500
Number of cylinders (PCS)6
Displacement (L)7.79
Working formDirect injection, 6 cylinders, 4 strokes, turbocharged, water cooled
Ground specific pressure (Kpa)68.8
Rotation speed (rpm)8.8
Climbing ability (%)70
Bucket digging force (kN)235
Rod digging force (kN)210
Travel speed (km/h)5.5/3.5
Fuel Tank (L)540
Engine Oil changes (L)36
Total transport length (mm)11425
Total transport width (mm)3190
Total transport height (mm)3825
Full cab height (mm)3440
Minimum ground clearance (mm)550
Minimum turning radius of front working device (mm)4390
Back end turning radius (mm)3610
Onboard width (mm)3230
Total track length (mm)5100
Track gauge (mm)2590
Track plate width (mm)600
Track ground length (mm)4140
Maximum height at minimum turning radius (mm)8930
Number of sprockets (single side) (each)2
Number of wheels (single side) (each)9
Number of track plates (single side) (PCS)49
Maximum digging radius (mm)10750
Maximum digging depth (mm)7155
Maximum excavation height (mm)9920
Maximum unloading height (mm)7010
Maximum vertical digging depth (mm)5125
see more

Overview

No.1049242

Brand Name:

Sany

Model Number:

SY375H

Year:

2021

Location:

Guangdong China

Pub Date
