Product Description
Built for high-output earthmoving and excavation work, this 2022 Sany SY375H delivers 37 tons of proven performance across construction, mining, and demolition sites. Powered by a robust GH-6HK1XKSC engine generating 212 kW at 2000 rpm, this machine combines 235 kN bucket digging force with a maximum digging depth of 7,155 mm to handle demanding soil conditions and deep foundation projects. Its 1.7-2.4 m³ bucket capacity moves material efficiently while maintaining precise control through an 8.8 rpm rotation speed.
Currently located in Shandong Linyi, this excavator arrives site-ready with key operational advantages:
- 10,750 mm maximum digging radius covers extensive working areas without repositioning
- 540-liter fuel tank supports extended shifts with minimal downtime
- 70% climbing ability navigates challenging terrain and steep grades
- Water-cooled turbocharged system ensures consistent power delivery under load
- 3,190 mm transport width allows standard flatbed hauling to your jobsite
Engineered in China with Sany's proven hydraulic architecture, this SY375H tackles grading, trenching, and material handling from day one. Ready to work.
| Specifications | Value |
|---|---|
| No. | 1024910 |
| Tonnage (tons) | 37 |
| Working weight (kg) | 37500 |
| Bucket capacity (m³) | 1.7-2.4 (1.9) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | GH-6HK1XKSC |
| Rated power (kw/rpm) | 212/2000 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 1080/1500 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 7.79 |
| Working form | Direct injection, 6 cylinders, 4 strokes, turbocharged, water cooled |
| Ground specific pressure (Kpa) | 68.8 |
| Rotation speed (rpm) | 8.8 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 235 |
| Rod digging force (kN) | 210 |
| Travel speed (km/h) | 5.5/3.5 |
| Fuel Tank (L) | 540 |
| Engine Oil changes (L) | 36 |
| Total transport length (mm) | 11425 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3825 |
| Full cab height (mm) | 3440 |
| Minimum ground clearance (mm) | 550 |
| Minimum turning radius of front working device (mm) | 4390 |
| Back end turning radius (mm) | 3610 |
| Onboard width (mm) | 3230 |
| Total track length (mm) | 5100 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 4140 |
| Maximum height at minimum turning radius (mm) | 8930 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 9 |
| Number of track plates (single side) (PCS) | 49 |
| Maximum digging radius (mm) | 10750 |
| Maximum digging depth (mm) | 7155 |
| Maximum excavation height (mm) | 9920 |
| Maximum unloading height (mm) | 7010 |
| Maximum vertical digging depth (mm) | 5125 |
