Product Description
Engineered with a robust GH-6HK1XKSC 6-cylinder turbocharged engine, this 2022 Sany SY375H delivers 212 kW of rated power at 2000 rpm and 1080 N·m maximum torque at 1500 rpm. Operating at 37 tons working weight with a 1.9 m³ bucket capacity, this excavator demonstrates exceptional digging performance with 235 kN bucket force and 210 kN arm force. The water-cooled, direct injection 7.79L displacement engine provides reliable power output for demanding applications.
- Maximum digging reach: 10,750 mm with 7,155 mm depth capability
- Superior vertical digging depth: 5,125 mm for precision trenching
- 8.8 rpm rotation speed ensures efficient cycle times
- Extended 5,100 mm track length with 4,140 mm ground contact for stability
- 540L fuel capacity supports extended operational periods
- 70% grading ability handles challenging terrain conditions
Currently located in Putian, Fujian, this Chinese-manufactured excavator combines proven hydraulic architecture with efficient power management. Dual-speed travel system (5.5/3.5 km/h) and 68.8 kPa ground pressure optimize both mobility and surface protection across varied job sites.
| Specifications | Value |
|---|---|
| No. | 1029708 |
| Tonnage (tons) | 37 |
| Working weight (kg) | 37500 |
| Bucket capacity (m³) | 1.7-2.4 (1.9) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | GH-6HK1XKSC |
| Rated power (kw/rpm) | 212/2000 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 1080/1500 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 7.79 |
| Working form | Direct injection, 6 cylinders, 4 strokes, turbocharged, water cooled |
| Ground specific pressure (Kpa) | 68.8 |
| Rotation speed (rpm) | 8.8 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 235 |
| Rod digging force (kN) | 210 |
| Travel speed (km/h) | 5.5/3.5 |
| Fuel Tank (L) | 540 |
| Engine Oil changes (L) | 36 |
| Total transport length (mm) | 11425 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3825 |
| Full cab height (mm) | 3440 |
| Minimum ground clearance (mm) | 550 |
| Minimum turning radius of front working device (mm) | 4390 |
| Back end turning radius (mm) | 3610 |
| Onboard width (mm) | 3230 |
| Total track length (mm) | 5100 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 4140 |
| Maximum height at minimum turning radius (mm) | 8930 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 9 |
| Number of track plates (single side) (PCS) | 49 |
| Maximum digging radius (mm) | 10750 |
| Maximum digging depth (mm) | 7155 |
| Maximum excavation height (mm) | 9920 |
| Maximum unloading height (mm) | 7010 |
| Maximum vertical digging depth (mm) | 5125 |
