Product Description
Powered by a robust 212kW Isuzu GH-6HK1XKSC engine, this 2022 Sany SY375H delivers dependable performance across demanding excavation projects. Operating at 37 tons with a 1.9m³ bucket capacity, this crawler excavator combines proven hydraulics with 235kN bucket digging force and a 10,750mm maximum reach. Sany's global service network ensures parts availability remains consistent throughout China and export markets, protecting your investment with accessible maintenance support. Currently located in Shenzhen, Guangdong, this machine represents exceptional value in the used equipment sector.
- Working Weight: 37,500kg with superior stability
- Engine: Water-cooled 6-cylinder Isuzu, 1,080N.m torque at 1,500rpm
- Reach & Depth: 10.75m digging radius, 7.155m maximum depth
- Fuel Efficiency: 540L tank capacity for extended operations
- Resale Advantage: Sany's strong brand recognition maintains competitive resale values
- Parts Network: Factory-direct components through established Chinese distribution channels
Backed by Sany's reputation as China's leading construction machin
| Specifications | Value |
|---|---|
| No. | 1031136 |
| Tonnage (tons) | 37 |
| Working weight (kg) | 37500 |
| Bucket capacity (m³) | 1.7-2.4 (1.9) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | GH-6HK1XKSC |
| Rated power (kw/rpm) | 212/2000 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 1080/1500 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 7.79 |
| Working form | Direct injection, 6 cylinders, 4 strokes, turbocharged, water cooled |
| Ground specific pressure (Kpa) | 68.8 |
| Rotation speed (rpm) | 8.8 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 235 |
| Rod digging force (kN) | 210 |
| Travel speed (km/h) | 5.5/3.5 |
| Fuel Tank (L) | 540 |
| Engine Oil changes (L) | 36 |
| Total transport length (mm) | 11425 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3825 |
| Full cab height (mm) | 3440 |
| Minimum ground clearance (mm) | 550 |
| Minimum turning radius of front working device (mm) | 4390 |
| Back end turning radius (mm) | 3610 |
| Onboard width (mm) | 3230 |
| Total track length (mm) | 5100 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 4140 |
| Maximum height at minimum turning radius (mm) | 8930 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 9 |
| Number of track plates (single side) (PCS) | 49 |
| Maximum digging radius (mm) | 10750 |
| Maximum digging depth (mm) | 7155 |
| Maximum excavation height (mm) | 9920 |
| Maximum unloading height (mm) | 7010 |
| Maximum vertical digging depth (mm) | 5125 |
