Product Description
Engineered for high-output performance, this 2024 Sany SY375H delivers 212 kW of rated power at 2000 rpm through its GH-6HK1XKSC turbocharged engine. The 6-cylinder, 7.79L direct injection powerplant generates 1080 N·m of maximum torque, providing consistent hydraulic force across demanding excavation cycles. Bucket digging force reaches 235 kN, while rod digging force achieves 210 kN—specifications that translate directly to productivity in high-density material applications.
Operating at 37 tons with a 1.9 m³ standard bucket capacity, this machine maintains optimal ground pressure at 68.8 kPa across a 4140 mm track ground length. Maximum digging reach extends to 10,750 mm, with vertical depth capability of 7,155 mm. The water-cooled system ensures thermal stability during extended operation, supported by a 540L fuel capacity for full-shift autonomy.
Currently positioned in Linyi, Shandong, this China-manufactured excavator represents Sany's proven hydraulic architecture in the 37-ton class. Transport dimensions of 11,425 × 3,190 × 3,825 mm facilitate logistics planning, while the 70% gradeability and 8.8 rpm rotation speed address site mobility requirements across variable terrain conditions.
| Specifications | Value |
|---|---|
| No. | 1024912 |
| Tonnage (tons) | 37 |
| Working weight (kg) | 37500 |
| Bucket capacity (m³) | 1.7-2.4 (1.9) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | GH-6HK1XKSC |
| Rated power (kw/rpm) | 212/2000 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 1080/1500 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 7.79 |
| Working form | Direct injection, 6 cylinders, 4 strokes, turbocharged, water cooled |
| Ground specific pressure (Kpa) | 68.8 |
| Rotation speed (rpm) | 8.8 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 235 |
| Rod digging force (kN) | 210 |
| Travel speed (km/h) | 5.5/3.5 |
| Fuel Tank (L) | 540 |
| Engine Oil changes (L) | 36 |
| Total transport length (mm) | 11425 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3825 |
| Full cab height (mm) | 3440 |
| Minimum ground clearance (mm) | 550 |
| Minimum turning radius of front working device (mm) | 4390 |
| Back end turning radius (mm) | 3610 |
| Onboard width (mm) | 3230 |
| Total track length (mm) | 5100 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 4140 |
| Maximum height at minimum turning radius (mm) | 8930 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 9 |
| Number of track plates (single side) (PCS) | 49 |
| Maximum digging radius (mm) | 10750 |
| Maximum digging depth (mm) | 7155 |
| Maximum excavation height (mm) | 9920 |
| Maximum unloading height (mm) | 7010 |
| Maximum vertical digging depth (mm) | 5125 |
