Product Description
With a working weight of 41,500 kg and a bucket capacity of 1.9/2.2 m³ (Rock), the Sany SY415H excavator from 2019 offers robust performance and reliability. Made in China, this model is powered by a 6UZ1 engine, delivering 257 kW at 2000 rpm, ensuring efficient operation on any job site. Its water-cooled, direct injection, 6-cylinder, 4-stroke, turbocharged engine provides a maximum torque of 1363 N.m at 1500 rpm, making it ideal for demanding tasks.
- Parts availability: Sany ensures easy access to genuine parts, minimizing downtime and maintenance costs.
- Resale value: Known for its durability and performance, the Sany SY415H retains strong resale value, making it a wise investment.
- High digging force: The bucket and rod digging forces of 247 kN and 218 kN, respectively, enhance productivity and efficiency.
- Superior mobility: With a travel speed of 5.3/3.2 km/h and a climbing ability of 70% (35°), this excavator can handle various terrains with ease.
Located in 四川泸州, this 2019 Sany SY415H is ready to meet your heavy machinery needs, backed by the brand's reputation for reliability and performance.
| Specifications | Value |
|---|---|
| No. | 1020859 |
| Tonnage (tons) | 41 |
| Working weight (kg) | 41500 |
| Bucket capacity (m³) | 1.9/2.2 (Rock) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | 6UZ1 |
| Rated power (kw/rpm) | 257/2000 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 1363/1500 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 9.839 |
| Working form | Direct injection, 6 cylinders, 4 strokes, turbocharged, water cooled |
| Ground specific pressure (Kpa) | 75.3 |
| Rotation speed (rpm) | 8.3 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 247 |
| Rod digging force (kN) | 218 |
| Travel speed (km/h) | 5.3/3.2 |
| Fuel Tank (L) | 690 |
| Engine Oil changes (L) | 36 |
| Total transport length (mm) | 11700 |
| Total transport width (mm) | 3360 |
| Total transport height (mm) | 3740 |
| Full cab height (mm) | 3470 |
| Minimum ground clearance (mm) | 505 |
| Minimum turning radius of front working device (mm) | 4750 |
| Back end turning radius (mm) | 3740 |
| Onboard width (mm) | 3265 |
| Total track length (mm) | 5320 |
| Track gauge (mm) | 2740 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 4340 |
| Maximum height at minimum turning radius (mm) | 8785 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 9 |
| Number of track plates (single side) (PCS) | 51 |
| Maximum digging radius (mm) | 10920 |
| Maximum digging depth (mm) | 7045 |
| Maximum excavation height (mm) | 9980 |
| Maximum unloading height (mm) | 6960 |
| Maximum vertical digging depth (mm) | 4710 |
