Product Description
With a rated power of 250 kW at 2000 rpm, the Sany SY425C excavator, manufactured in Kunshan, Jiangsu Province, is designed for robust performance. Ideal for digging, grading, and demolition, this 42-ton machine boasts a working weight of 42,900 kg and a bucket capacity of 2 m³. Its backhoe bucket delivers a digging force of 267 kN, ensuring efficient excavation. The SY425C offers a maximum digging depth of 7,290 mm and a maximum digging radius of 11,545 mm, making it versatile for various construction tasks. With a travel speed of up to 5.2 km/h, this excavator is ready to tackle demanding job sites. Key features include a ground specific pressure of 80 Kpa, a climbing ability of 35°, and a total transport width of 3,340 mm, ensuring stability and maneuverability. Get your site-ready Sany SY425C today and enhance your project's productivity.
| Specifications | Value |
|---|---|
| No. | 1000335 |
| Tonnage (tons) | 42 |
| Working weight (kg) | 42900 |
| Bucket capacity (m³) | 2 |
| Country of origin | Kunshan in Jiangsu Province |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 250/2000 |
| Ground specific pressure (Kpa) | 80 |
| Rotation speed (rpm) | 9.5 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 267 |
| Rod digging force (kN) | 241 |
| Travel speed (km/h) | 5.2/3.2 |
| Total transport length (mm) | 12090 |
| Total transport width (mm) | 3340 |
| Total transport height (mm) | 3690 |
| Full cab height (mm) | 3230 |
| Minimum ground clearance (mm) | 560 |
| Minimum turning radius of front working device (mm) | 4940 |
| Back end turning radius (mm) | 3750 |
| Total track length (mm) | 5015 |
| Track gauge (mm) | 2740 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3340 |
| Track ground length (mm) | 4020 |
| Maximum digging radius (mm) | 11545 |
| Maximum digging depth (mm) | 7290 |
| Maximum excavation height (mm) | 10665 |
| Maximum unloading height (mm) | 7410 |
| Bulldozer lift or depth (mm) | There is no |
| Dodging plate width × height (mm) | There is no |
