Product Description
Engineered for demanding excavation projects, this 2016 Sany SY465C delivers 46-ton performance with precision control and robust stability. Powered by a 250kW engine at 2000 rpm, this crawler excavator combines substantial digging force with refined operator handling. The spacious cabin provides commanding visibility across the 11.5-meter maximum digging radius, while intuitive controls ensure responsive bucket and arm movements throughout extended shifts.
Operators benefit from excellent ground-level stability, with 77 kPa ground pressure distributed across 600mm track plates and a 2740mm track gauge. The 9.5 rpm rotation speed enables smooth, controlled positioning without sacrificing cycle times. Climbing capability reaches 70% grade (35°), supported by a low center of gravity and 560mm ground clearance for challenging terrain navigation.
- Working Weight: 45,500 kg with 2.2 m³ bucket capacity
- Digging Performance: 267 kN bucket force, 241 kN arm force
- Maximum Digging Depth: 7,285 mm
- Compact Turning: 3,750 mm rear radius for confined sites
- Transport Dimensions: 12,090 × 3,340 × 3,690 mm
- Current Location: Changzhou, Jiangsu Province, China
| Specifications | Value |
|---|---|
| No. | 1034278 |
| Tonnage (tons) | 46 |
| Working weight (kg) | 45500 |
| Bucket capacity (m³) | 2.2 |
| Country of origin | Kunshan in Jiangsu Province |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 250/2000 |
| Ground specific pressure (Kpa) | 77 |
| Rotation speed (rpm) | 9.5 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 267 |
| Rod digging force (kN) | 241 |
| Travel speed (km/h) | 5.2/3.2 |
| Total transport length (mm) | 12090 |
| Total transport width (mm) | 3340 |
| Total transport height (mm) | 3690 |
| Full cab height (mm) | 3230 |
| Minimum ground clearance (mm) | 560 |
| Minimum turning radius of front working device (mm) | 4940 |
| Back end turning radius (mm) | 3750 |
| Total track length (mm) | 5030 |
| Track gauge (mm) | 2740 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3340 |
| Track ground length (mm) | 4070 |
| Maximum digging radius (mm) | 11545 |
| Maximum digging depth (mm) | 7285 |
| Maximum excavation height (mm) | 10665 |
| Maximum unloading height (mm) | 7410 |
| Bulldozer lift or depth (mm) | There is no |
| Dodging plate width × height (mm) | There is no |
