Product Description
Built for heavy-duty excavation and demolition work, this 2018 Sany SY475H delivers 48-ton class performance with proven reliability. Powered by a 257kW engine at 2000rpm, this machine tackles demanding dig cycles with 287kN bucket digging force and 245kN arm digging force—engineered to move material efficiently on any jobsite. Currently located in Huizhou, Guangdong, this excavator arrives site-ready with a 2.2m³ backhoe bucket configuration ideal for trenching, foundation work, and mass excavation projects.
- Operating weight: 48,500kg with optimal stability
- Bucket capacity: 2.2m³ for high-volume material handling
- Rotation speed: 8rpm for productive cycle times
- Travel speed: 5.4km/h (high) / 3.1km/h (low)
- Climbing ability: 70% grade capability
- Ground pressure: 85.3kPa minimizes surface damage
- Compact tail swing: 3765mm rear turning radius
- 600mm track plates on 2740mm gauge for superior traction
Made in China with traditional power systems, this machine is ready for immediate deployment in construction, mining, or land development operations. Inspect in Huizhou—put it to work tomorrow.
| Specifications | Value |
|---|---|
| No. | 1021481 |
| Tonnage (tons) | 48 |
| Working weight (kg) | 48500 |
| Bucket capacity (m³) | 2.2 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 257kW/2000rpm |
| Ground specific pressure (Kpa) | 85.3 |
| Rotation speed (rpm) | 8 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 287 |
| Rod digging force (kN) | 245 |
| Travel speed (km/h) | 5.4/3.1 |
| Back end turning radius (mm) | 3765 |
| Track gauge (mm) | 2740 |
| Track plate width (mm) | 600 |
