2020 Sany SY550H

1/7
Buy Sany SY550H Used Excavator / 1
Buy Sany SY550H Used Excavator / 2
Buy Sany SY550H Used Excavator / 3
Buy Sany SY550H Used Excavator / 4
Buy Sany SY550H Used Excavator / 5
Buy Sany SY550H Used Excavator / 6
Buy Sany SY550H Used Excavator / 7

Product Description

With a working weight of 51,000 kg and a bucket capacity ranging from 3.1 to 3.5 m³, the Sany SY550H excavator, manufactured in 2020, stands as a testament to durability and reliability. Built in China, this machine has proven its worth on numerous challenging sites, making it a trusted workhorse for demanding operations. Powered by a robust engine with a rated power of 300 kW at 1800 rpm, it delivers consistent performance. Its ground specific pressure of 87.1 Kpa ensures stability even in soft terrains, while the climbing ability of 70% and travel speed of up to 5.4 km/h enhance its versatility. The SY550H boasts a total transport length of 12,095 mm, width of 3,360 mm, and height of 3,790 mm, making it suitable for various job site requirements. Located in 江苏常州, this excavator is ready to tackle your next project with unmatched resilience.

SpecificationsValue
No.1045825
Tonnage (tons)55
Working weight (kg)51000
Bucket capacity (m³)3.1-3.5
powerTraditional power
manufacturerMade in China
bucketbackhoe
Rated power (kw/rpm)300/1800
Ground specific pressure (Kpa)87.1
Rotation speed (rpm)8
Climbing ability (%)70
Travel speed (km/h)5.4/3.1
Total transport length (mm)12095
Total transport width (mm)3360
Total transport height (mm)3790
Full cab height (mm)3470
Minimum ground clearance (mm)560
Back end turning radius (mm)3765
Onboard width (mm)3290
Total track length (mm)5440
Track gauge (mm)2740
Track plate width (mm)600
Track ground length (mm)4415
Maximum digging radius (mm)12841 (broken)
Maximum digging depth (mm)8077 (broken)
Maximum excavation height (mm)12279 (broken)
Maximum excavation radius of stop surface (mm)10655 (broken)
see more

Overview

No.1045825

Brand Name:

Sany

Model Number:

SY550H

Year:

2020

Location:

Jiangsu China
