Product Description
Built for the toughest jobsites, this 2022 Sany SY550H excavator delivers proven reliability with minimal operational hours. Operating at 55 tons with a robust 51,000 kg working weight, this machine represents Sany's commitment to durability in heavy-duty construction environments. Powered by a 300 kw engine at 1800 rpm, it maintains consistent performance across demanding applications from deep excavation to heavy material handling.
Key specifications demonstrate its workhorse capabilities:
- Maximum digging reach of 12,841 mm with exceptional depth capacity of 8,077 mm
- Bucket capacity range of 3.1-3.5 m³ for high-volume productivity
- Ground pressure of just 87.1 Kpa minimizes surface damage while maximizing stability
- 70% climbing ability tackles challenging terrain with confidence
- 600 mm track plates and 4,415 mm ground contact length ensure superior traction
Currently located in Shandong Linyi, China, this machine combines traditional power reliability with modern engineering. Factory-backed construction quality means reduced downtime and lower operating costs over the machine's lifetime. Ready for immediate deployment on large-scale earthmoving, mining, or infr
| Specifications | Value |
|---|---|
| No. | 1026164 |
| Tonnage (tons) | 55 |
| Working weight (kg) | 51000 |
| Bucket capacity (m³) | 3.1-3.5 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 300/1800 |
| Ground specific pressure (Kpa) | 87.1 |
| Rotation speed (rpm) | 8 |
| Climbing ability (%) | 70 |
| Travel speed (km/h) | 5.4/3.1 |
| Total transport length (mm) | 12095 |
| Total transport width (mm) | 3360 |
| Total transport height (mm) | 3790 |
| Full cab height (mm) | 3470 |
| Minimum ground clearance (mm) | 560 |
| Back end turning radius (mm) | 3765 |
| Onboard width (mm) | 3290 |
| Total track length (mm) | 5440 |
| Track gauge (mm) | 2740 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 4415 |
| Maximum digging radius (mm) | 12841 (broken) |
| Maximum digging depth (mm) | 8077 (broken) |
| Maximum excavation height (mm) | 12279 (broken) |
| Maximum excavation radius of stop surface (mm) | 10655 (broken) |
