Product Description
Commanding a 55-ton operating class, this 2022 Sany SY550H excavator delivers precision control and robust stability for demanding earthmoving operations. Operators benefit from excellent all-around visibility within the full-height cabin, positioned 3,470mm above ground to provide clear sightlines across the 12.8-meter working envelope. The machine's 600mm-wide track plates and 2,740mm gauge distribute 51,000kg of working weight efficiently, maintaining ground pressure at just 87.1 kPa for confident performance on variable terrain.
- 300kW rated power at 1,800 rpm for consistent hydraulic response
- 3.1-3.5m³ backhoe bucket capacity suited to high-volume excavation
- 8 rpm swing speed enables smooth, controlled rotation cycles
- 70% gradeability and 560mm ground clearance for jobsite mobility
- Dual travel speeds (5.4/3.1 km/h) balance productivity and precision
- Maximum digging depth of 8,077mm reaches deep trench requirements
Built in China and currently located in Hunan, this traditional diesel-powered excavator combines proven mechanical architecture with operator-focused ergonomics for reliable daily performance.
| Specifications | Value |
|---|---|
| No. | 1034196 |
| Tonnage (tons) | 55 |
| Working weight (kg) | 51000 |
| Bucket capacity (m³) | 3.1-3.5 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 300/1800 |
| Ground specific pressure (Kpa) | 87.1 |
| Rotation speed (rpm) | 8 |
| Climbing ability (%) | 70 |
| Travel speed (km/h) | 5.4/3.1 |
| Total transport length (mm) | 12095 |
| Total transport width (mm) | 3360 |
| Total transport height (mm) | 3790 |
| Full cab height (mm) | 3470 |
| Minimum ground clearance (mm) | 560 |
| Back end turning radius (mm) | 3765 |
| Onboard width (mm) | 3290 |
| Total track length (mm) | 5440 |
| Track gauge (mm) | 2740 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 4415 |
| Maximum digging radius (mm) | 12841 (broken) |
| Maximum digging depth (mm) | 8077 (broken) |
| Maximum excavation height (mm) | 12279 (broken) |
| Maximum excavation radius of stop surface (mm) | 10655 (broken) |
