Product Description
With a working weight of 51,000 kg and a robust 55-ton capacity, the Sany SY550H excavator stands as a testament to enduring engineering. Built in 2022, this machine has already established itself as a reliable workhorse, capable of handling the most demanding tasks with ease. Featuring a powerful 300 kW engine, it delivers consistent performance at 1800 rpm, ensuring that every job is completed efficiently. The SY550H boasts a maximum digging depth of 8077 mm and a maximum excavation height of 12279 mm, making it versatile for a wide range of applications. Its ground specific pressure of 87.1 Kpa and climbing ability of 70% further enhance its capability in challenging terrains. This model, made in China, is designed for durability and reliability, making it a trusted choice for heavy-duty construction projects.
| Specifications | Value |
|---|---|
| No. | 1058008 |
| Tonnage (tons) | 55 |
| Working weight (kg) | 51000 |
| Bucket capacity (m³) | 3.1-3.5 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 300/1800 |
| Ground specific pressure (Kpa) | 87.1 |
| Rotation speed (rpm) | 8 |
| Climbing ability (%) | 70 |
| Travel speed (km/h) | 5.4/3.1 |
| Total transport length (mm) | 12095 |
| Total transport width (mm) | 3360 |
| Total transport height (mm) | 3790 |
| Full cab height (mm) | 3470 |
| Minimum ground clearance (mm) | 560 |
| Back end turning radius (mm) | 3765 |
| Onboard width (mm) | 3290 |
| Total track length (mm) | 5440 |
| Track gauge (mm) | 2740 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 4415 |
| Maximum digging radius (mm) | 12841 (broken) |
| Maximum digging depth (mm) | 8077 (broken) |
| Maximum excavation height (mm) | 12279 (broken) |
| Maximum excavation radius of stop surface (mm) | 10655 (broken) |
