Product Description
Strengthen your fleet with this reliable 2016 Sany SY65C-9 mini excavator, currently located in Guizhou and ready for immediate deployment. Built in Shanghai with proven Isuzu AJ-4JG1 power, this 6-ton workhorse delivers 40.9kW at 2100rpm through a water-cooled, 4-cylinder engine. Contractors seeking dependable backup equipment will appreciate its robust hydraulic system featuring a variable swashplate plunger pump with 149 l/min maximum flow and 26 MPa main overflow pressure.
Performance specifications include:
- Operating weight: 6,700 kg with 0.25 m³ bucket capacity (expandable 0.16-0.32 m³)
- Maximum digging reach: 6,235 mm; digging depth: 4,065 mm
- Bucket digging force: 51 kN; arm digging force: 35.6 kN
- Compact transport dimensions: 6,120 mm (L) × 2,140 mm (W) × 2,645 mm (H)
- Impressive 70% (35°) climbing ability with 11.5 rpm rotation speed
With 130L fuel capacity and efficient hydraulics, this machine maintains productivity across extended shifts. Add proven Chinese manufacturing quality to your operation without breaking your equipment budget.
| Specifications | Value |
|---|---|
| No. | 999960 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 6700 |
| Bucket capacity (m³) | 0.25 (optional 0.16 ~ 0.32) |
| Country of origin | Shanghai |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Isuzu AJ-4JG1 |
| Rated power (kw/rpm) | 40.9/2100 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.059 |
| Ground specific pressure (Kpa) | 33 |
| Rotation speed (rpm) | 11.5 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 51 |
| Rod digging force (kN) | 35.6 |
| Travel speed (km/h) | 4.2/2.4 |
| Main overflow set pressure (Mpa) | 26 |
| Maximum flow of main pump (l/min) | 149 |
| Traveling Hydraulic Circuit (Mpa) | 26 |
| Rotary Hydraulic Circuit (Mpa) | 21.6 |
| Control Hydraulic Circuit (Mpa) | 3.6 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Variable swashplate plunger pump |
| Bucket cylinders - Number × diameter × stroke (mm) | 80 x 730 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 90 x 900 |
| Boom cylinders - Number × diameter × stroke (mm) | 110 x 885 |
| Fuel Tank (L) | 130 |
| Hydraulic Tank (L) | 100 |
| Engine Oil changes (L) | 10 |
| Coolant (L) | 12 |
| Total transport length (mm) | 6120 |
| Total transport width (mm) | 2140 |
| Total transport height (mm) | 2645 |
| Minimum ground clearance (mm) | 370 |
| Back end turning radius (mm) | 1800 |
| Onboard width (mm) | 2040 |
| Total track length (mm) | 2700 |
| Track gauge (mm) | 1600 |
| Track plate width (mm) | 400 |
| Total track width (mm) | 2160 |
| Track ground length (mm) | 2180 |
| Maximum digging radius (mm) | 6235 |
| Maximum digging depth (mm) | 4065 |
| Maximum excavation height (mm) | 7010 |
| Maximum unloading height (mm) | 5110 |
| Maximum vertical digging depth (mm) | 3335 |
| Bulldozer lift or depth (mm) | Lift 300/ push 405 |
| Dodging plate width × height (mm) | Altitude 405 |
