Product Description
Proven in demanding conditions since 2020, this Sany SY70C mini excavator demonstrates the durability that defines reliable heavy equipment. With a robust 6,800 kg working weight and powerful V2607-DI-T-ET06e engine delivering 45.4 kW at 2400 rpm, this 7-ton workhorse handles challenging excavation tasks with consistent performance. Its impressive 51 kN bucket digging force and 4,065 mm maximum effective digging depth make it a versatile solution for construction, landscaping, and utility projects.
Currently located in Yunnan, this backhoe-equipped excavator features water-cooled efficiency and a generous 150L fuel tank for extended operation. Built to last through rigorous job sites, it offers 70% climbing ability and 33 Kpa ground pressure for exceptional stability on varied terrain. The compact transport dimensions (6,120 x 2,140 x 2,645 mm) ensure easy mobilization between projects.
- Bucket capacity: 0.28 m³ (range: 0.12-0.32 m³)
- Maximum excavation height: 7,010 mm
- Maximum unloading height: 5,110 mm
- Travel speed: 4.2/2.4 km/h
- Made in China with proven reliability
| Specifications | Value |
|---|---|
| No. | 1019104 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 6800 |
| Bucket capacity (m³) | 0.12~0.32 (0.28) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | V2607-DI-T-ET06e |
| Rated power (kw/rpm) | 45.4/2400 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 217/1600 |
| Displacement (L) | 2.615 |
| Ground specific pressure (Kpa) | 33 |
| Rotation speed (rpm) | 11.5 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 51 |
| Rod digging force (kN) | 36 |
| Travel speed (km/h) | 4.2/2.4 |
| Fuel Tank (L) | 150 |
| Hydraulic Tank (L) | 120 |
| Engine Oil changes (L) | 10 |
| Total transport length (mm) | 6120 |
| Total transport width (mm) | 2140 |
| Total transport height (mm) | 2645 |
| Track plate width (mm) | 400 |
| Number of sprockets (single side) (each) | 1 |
| Number of wheels (single side) (each) | 5 |
| Number of track plates (single side) (PCS) | 42 |
| Maximum excavation height (mm) | 7010 |
| Maximum unloading height (mm) | 5110 |
| Maximum vertical digging depth (mm) | 3335 |
| Maximum effective digging depth (mm) | 4065 |
