Product Description
With a working weight of 6800 kg and a bucket capacity ranging from 0.12 to 0.32 m³, this 2021 Sany SY70C excavator is an ideal fleet addition for contractors needing reliable performance. Equipped with a V2607-DI-T-ET06e engine, it delivers 45.4 kW at 2400 rpm, ensuring robust power for demanding tasks. Its maximum torque of 217 N.m at 1600 rpm and a climbing ability of 70% make it versatile across various terrains.
- Bucket digging force: 51 kN
- Travel speed: 4.2/2.4 km/h
- Fuel Tank: 150 L
- Total transport dimensions: 6120 mm (L) x 2140 mm (W) x 2645 mm (H)
- Maximum excavation height: 7010 mm
Integrate this Sany SY70C into your fleet for enhanced productivity and reliability, making it a valuable asset for any busy construction site in Zhejiang, China, or beyond.
| Specifications | Value |
|---|---|
| No. | 1056677 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 6800 |
| Bucket capacity (m³) | 0.12~0.32 (0.28) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | V2607-DI-T-ET06e |
| Rated power (kw/rpm) | 45.4/2400 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 217/1600 |
| Displacement (L) | 2.615 |
| Ground specific pressure (Kpa) | 33 |
| Rotation speed (rpm) | 11.5 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 51 |
| Rod digging force (kN) | 36 |
| Travel speed (km/h) | 4.2/2.4 |
| Fuel Tank (L) | 150 |
| Hydraulic Tank (L) | 120 |
| Engine Oil changes (L) | 10 |
| Total transport length (mm) | 6120 |
| Total transport width (mm) | 2140 |
| Total transport height (mm) | 2645 |
| Track plate width (mm) | 400 |
| Number of sprockets (single side) (each) | 1 |
| Number of wheels (single side) (each) | 5 |
| Number of track plates (single side) (PCS) | 42 |
| Maximum excavation height (mm) | 7010 |
| Maximum unloading height (mm) | 5110 |
| Maximum vertical digging depth (mm) | 3335 |
| Maximum effective digging depth (mm) | 4065 |
