Product Description
Built for high-demand excavation projects, this 2016 Sany SY750H delivers 75-ton performance with exceptional operator control. Powered by a robust 377 kW engine at 1800 rpm, this Chinese-manufactured excavator combines 402 kN bucket digging force with 345 kN rod digging force to handle challenging ground conditions efficiently.
Operator-focused design ensures precision and comfort during extended shifts. The spacious cabin provides commanding visibility from 3800 mm above ground, while intuitive controls manage the 7.3 rpm rotation speed for smooth, predictable movement. Ground-specific pressure of just 110 kPa distributes the 76,200 kg working weight evenly, delivering remarkable stability across soft terrain without sacrificing productivity.
- Maximum digging reach: 12,050 mm with 7,620 mm depth capability
- Bucket capacity: 4.6–5.6 m³ for versatile material handling
- Travel speeds: 4.5/2.9 km/h for efficient site mobility
- 70% climbing ability tackles steep gradients confidently
- Currently located in Hunan, China—ready for global shipment
Proven reliability meets operator efficiency in this well-maintained heavy excavator, ideal for mining, quarrying, and large-sc
| Specifications | Value |
|---|---|
| No. | 1024664 |
| Tonnage (tons) | 75 |
| Working weight (kg) | 76200 |
| Bucket capacity (m³) | 4.6-5.6 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 377/1800 |
| Ground specific pressure (Kpa) | 110 |
| Rotation speed (rpm) | 7.3 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 402 |
| Rod digging force (kN) | 345 |
| Travel speed (km/h) | 4.5/2.9 |
| Total transport length (mm) | 12865 |
| Total transport width (mm) | 4320 |
| Total transport height (mm) | 4855 |
| Full cab height (mm) | 3800 |
| Minimum ground clearance (mm) | 880 |
| Minimum turning radius of front working device (mm) | 5520 |
| Back end turning radius (mm) | 4220 |
| Onboard width (mm) | 3460 |
| Total track length (mm) | 5865 |
| Track gauge (mm) | 3380/2780 |
| Track plate width (mm) | 650 |
| Track ground length (mm) | 4650 |
| Maximum height at minimum turning radius (mm) | 9780 |
| Maximum digging radius (mm) | 12050 |
| Maximum digging depth (mm) | 7620 |
| Maximum excavation height (mm) | 11200 |
| Maximum unloading height (mm) | 7250 |
| Maximum vertical digging depth (mm) | 4320 |
