Product Description
Engineered for large-scale earthmoving operations, this 2018 Sany SY750H delivers 377 kW of rated power at 1,800 rpm through a proven traditional powertrain. With an operating weight of 76,200 kg and bucket capacity ranging from 4.6 to 5.6 m³, this 75-ton excavator combines robust hydraulic performance with exceptional reach capabilities—achieving a maximum digging radius of 12,050 mm and excavation depth of 7,620 mm.
- Bucket digging force: 402 kN; rod digging force: 345 kN
- Maximum excavation height: 11,200 mm with 7,250 mm unloading clearance
- Ground-specific pressure of 110 kPa ensures stability across varied terrain
- 70% climbing ability with dual travel speeds (4.5/2.9 km/h)
- Compact 4,220 mm rear turning radius for confined job sites
- Currently located in Guizhou, China—ready for international export
Built to Chinese manufacturing standards, the SY750H series represents Sany's commitment to heavy-duty reliability in mining, quarrying, and infrastructure projects. Complete backhoe configuration with 650 mm track plates provides optimal traction and production efficiency.
| Specifications | Value |
|---|---|
| No. | 1019131 |
| Tonnage (tons) | 75 |
| Working weight (kg) | 76200 |
| Bucket capacity (m³) | 4.6-5.6 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 377/1800 |
| Ground specific pressure (Kpa) | 110 |
| Rotation speed (rpm) | 7.3 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 402 |
| Rod digging force (kN) | 345 |
| Travel speed (km/h) | 4.5/2.9 |
| Total transport length (mm) | 12865 |
| Total transport width (mm) | 4320 |
| Total transport height (mm) | 4855 |
| Full cab height (mm) | 3800 |
| Minimum ground clearance (mm) | 880 |
| Minimum turning radius of front working device (mm) | 5520 |
| Back end turning radius (mm) | 4220 |
| Onboard width (mm) | 3460 |
| Total track length (mm) | 5865 |
| Track gauge (mm) | 3380/2780 |
| Track plate width (mm) | 650 |
| Track ground length (mm) | 4650 |
| Maximum height at minimum turning radius (mm) | 9780 |
| Maximum digging radius (mm) | 12050 |
| Maximum digging depth (mm) | 7620 |
| Maximum excavation height (mm) | 11200 |
| Maximum unloading height (mm) | 7250 |
| Maximum vertical digging depth (mm) | 4320 |
