Product Description
Expand your operational capacity with this 2018 Sany SY750H excavator, a proven 75-ton workhorse engineered for contractors managing multiple jobsites simultaneously. Powered by a robust 377kW engine and equipped with a 4.6-5.6m³ bucket, this machine delivers consistent performance across demolition, mining, and large-scale earthmoving projects. Currently stationed in Putian, Fujian, it offers immediate deployment potential for fleet managers seeking to minimize downtime during peak construction seasons.
- Digging Performance: 12,050mm maximum reach with 402kN bucket force ensures productivity on demanding excavation tasks
- Transport Efficiency: Compact 12,865mm transport length simplifies logistics between sites
- Operational Reliability: 76,200kg working weight provides stability for continuous operation in challenging terrain
- Versatile Application: 7,620mm digging depth handles deep foundation work and utility installations
Backed by Sany's proven hydraulic systems and factory specifications, this backhoe-equipped excavator integrates seamlessly with existing CAT, Komatsu, or Hitachi fleets. Its 4.5km/h travel sp
| Specifications | Value |
|---|---|
| No. | 1028539 |
| Tonnage (tons) | 75 |
| Working weight (kg) | 76200 |
| Bucket capacity (m³) | 4.6-5.6 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 377/1800 |
| Ground specific pressure (Kpa) | 110 |
| Rotation speed (rpm) | 7.3 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 402 |
| Rod digging force (kN) | 345 |
| Travel speed (km/h) | 4.5/2.9 |
| Total transport length (mm) | 12865 |
| Total transport width (mm) | 4320 |
| Total transport height (mm) | 4855 |
| Full cab height (mm) | 3800 |
| Minimum ground clearance (mm) | 880 |
| Minimum turning radius of front working device (mm) | 5520 |
| Back end turning radius (mm) | 4220 |
| Onboard width (mm) | 3460 |
| Total track length (mm) | 5865 |
| Track gauge (mm) | 3380/2780 |
| Track plate width (mm) | 650 |
| Track ground length (mm) | 4650 |
| Maximum height at minimum turning radius (mm) | 9780 |
| Maximum digging radius (mm) | 12050 |
| Maximum digging depth (mm) | 7620 |
| Maximum excavation height (mm) | 11200 |
| Maximum unloading height (mm) | 7250 |
| Maximum vertical digging depth (mm) | 4320 |
