Product Description
With a powerful 377 kW engine and a robust 75-ton working weight, this Sany SY750H excavator, manufactured in 2019, is a formidable tool for your construction site. Located in 江苏, it's ready to tackle demanding tasks such as digging, grading, and demolition with precision and efficiency.
- Bucket capacity ranges from 4.6 to 5.6 m³, ideal for large-scale excavation projects.
- Impressive bucket digging force of 402 kN and rod digging force of 345 kN ensure tough jobs are handled with ease.
- Travel speed of 4.5 km/h and 2.9 km/h on rough terrain, making it versatile for various site conditions.
- Ground specific pressure of 110 Kpa minimizes ground damage, suitable for sensitive work environments.
- Maximum digging depth of 7620 mm and maximum unloading height of 7250 mm, providing extensive operational reach.
This excavator is fully equipped and site-ready, ensuring you can start your project without delay.
| Specifications | Value |
|---|---|
| No. | 1032538 |
| Tonnage (tons) | 75 |
| Working weight (kg) | 76200 |
| Bucket capacity (m³) | 4.6-5.6 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 377/1800 |
| Ground specific pressure (Kpa) | 110 |
| Rotation speed (rpm) | 7.3 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 402 |
| Rod digging force (kN) | 345 |
| Travel speed (km/h) | 4.5/2.9 |
| Total transport length (mm) | 12865 |
| Total transport width (mm) | 4320 |
| Total transport height (mm) | 4855 |
| Full cab height (mm) | 3800 |
| Minimum ground clearance (mm) | 880 |
| Minimum turning radius of front working device (mm) | 5520 |
| Back end turning radius (mm) | 4220 |
| Onboard width (mm) | 3460 |
| Total track length (mm) | 5865 |
| Track gauge (mm) | 3380/2780 |
| Track plate width (mm) | 650 |
| Track ground length (mm) | 4650 |
| Maximum height at minimum turning radius (mm) | 9780 |
| Maximum digging radius (mm) | 12050 |
| Maximum digging depth (mm) | 7620 |
| Maximum excavation height (mm) | 11200 |
| Maximum unloading height (mm) | 7250 |
| Maximum vertical digging depth (mm) | 4320 |
