Product Description
Based in Jiangsu Lianyungang and available for immediate dispatch, this 2016 Sany SY75C-8 compact excavator eliminates factory lead times and gets your crew productive fast. Operating at 6,800 kg working weight with a 0.28 m³ backhoe bucket, this 7-ton machine delivers 49 kN bucket digging force and reaches 4,060 mm maximum digging depth. Powered by an Isuzu CC-4JG1PAC engine rated at 40 kW, it combines reliability with efficient water-cooling for extended operation in demanding conditions.
- Ready to Ship: Skip months of factory delays—available now from Jiangsu Lianyungang
- Proven Performance: 6,250 mm maximum digging radius, 7,070 mm max digging height
- Versatile Mobility: 2.6–4.2 km/h travel speed, 70% gradeability, 1,720 mm tight tail swing
- Hydraulic Power: 149 L/min main pump flow, 26 MPa traveling circuit pressure
- Compact Footprint: 6,000 mm transport length, 2,220 mm width for easy site access
Fast deployment means faster ROI. Contact Fair Trade Machinery today to arrange inspection and shipping to your worksite.
| Specifications | Value |
|---|---|
| No. | 1032951 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 6800 |
| Bucket capacity (m³) | 0.28 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Isuzu CC-4JG1PAC |
| Rated power (kw/rpm) | 40/2100 |
| Cooling mode | water-cooling |
| Ground specific pressure (Kpa) | 28 |
| Rotation speed (rpm) | 10.9 |
| Climbing ability (%) | 70% / 35 ° |
| Bucket digging force (kN) | 49 |
| Rod digging force (kN) | 35 |
| Travel speed (km/h) | 2.6-4.2 |
| Maximum flow of main pump (l/min) | 149 |
| Traveling Hydraulic Circuit (Mpa) | 26 |
| Rotary Hydraulic Circuit (Mpa) | 21.6 |
| Control Hydraulic Circuit (Mpa) | 3.6 |
| Hydraulic crushing pipeline is standard | no |
| Total transport length (mm) | 6000 |
| Total transport width (mm) | 2220 |
| Total transport height (mm) | 2620 |
| Full cab height (mm) | 2620 |
| Minimum ground clearance (mm) | 355 |
| Back end turning radius (mm) | 1720 |
| Total track length (mm) | 2710 |
| Track gauge (mm) | 1750 |
| Track plate width (mm) | 450 |
| Total track width (mm) | 2220 |
| Track ground length (mm) | 2170 |
| Maximum digging radius (mm) | 6250 |
| Maximum digging depth (mm) | 4060 |
| Maximum excavation height (mm) | 7070 |
| Maximum unloading height (mm) | 5110 |
| Maximum vertical digging depth (mm) | 3410 |
| Bulldozer lift or depth (mm) | 390 |
