Product Description
This 2020 Sany SY75C-8 compact hydraulic excavator is currently located in Sichuan, China, and is available for immediate inspection by qualified buyers. The machine is on-site with the seller present, facilitating direct viewing and operational demonstrations.
The SY75C-8 represents Sany's reliable 7.5-ton class excavator, designed for versatility in construction, landscaping, and light demolition applications. This model features Sany's proven hydraulic system, offering efficient performance and fuel economy in its class.
Key attributes include:
- Operating weight: approximately 7,500 kg
- Compact footprint suitable for confined job sites
- Standard swing boom configuration
- Rubber track undercarriage for reduced ground disturbance
- Enclosed operator cabin with climate control
This unit is suited for contractors seeking dependable mid-size excavation equipment with established parts availability across international markets. Inspection appointments can be arranged directly at the Sichuan location.
| Specifications | Value |
|---|---|
| No. | 1088993 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 6800 |
| Bucket capacity (m³) | 0.28 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Isuzu CC-4JG1PAC |
| Rated power (kw/rpm) | 40/2100 |
| Cooling mode | water-cooling |
| Ground specific pressure (Kpa) | 28 |
| Rotation speed (rpm) | 10.9 |
| Climbing ability (%) | 70% / 35 ° |
| Bucket digging force (kN) | 49 |
| Rod digging force (kN) | 35 |
| Travel speed (km/h) | 2.6-4.2 |
| Maximum flow of main pump (l/min) | 149 |
| Traveling Hydraulic Circuit (Mpa) | 26 |
| Rotary Hydraulic Circuit (Mpa) | 21.6 |
| Control Hydraulic Circuit (Mpa) | 3.6 |
| Hydraulic crushing pipeline is standard | no |
| Total transport length (mm) | 6000 |
| Total transport width (mm) | 2220 |
| Total transport height (mm) | 2620 |
| Full cab height (mm) | 2620 |
| Minimum ground clearance (mm) | 355 |
| Back end turning radius (mm) | 1720 |
| Total track length (mm) | 2710 |
| Track gauge (mm) | 1750 |
| Track plate width (mm) | 450 |
| Total track width (mm) | 2220 |
| Track ground length (mm) | 2170 |
| Maximum digging radius (mm) | 6250 |
| Maximum digging depth (mm) | 4060 |
| Maximum excavation height (mm) | 7070 |
| Maximum unloading height (mm) | 5110 |
| Maximum vertical digging depth (mm) | 3410 |
| Bulldozer lift or depth (mm) | 390 |
