Product Description
Backed by one of the world's largest construction equipment manufacturers, this 2022 Sany SY870H delivers 87 tons of proven excavation power with the global parts network to keep it running. Operating at 377 kW and weighing 78,600 kg, this backhoe excavator handles bucket capacities from 5.0 to 6.5 m³ while maintaining exceptional digging force of 432 kN. Currently located in Lishui, Zhejiang, this machine represents smart investment in a brand known for widespread dealer support and strong resale retention across international markets.
- Maximum Digging Reach: 11,703 mm with 7,247 mm depth capability
- Performance: 7.7 rpm rotation speed, 70% climbing ability
- Transport Dimensions: 13,002 × 4,320 × 4,742 mm
- Track Configuration: 650 mm plates, 3,380 mm operational gauge
- Ground Clearance: 880 mm for challenging terrain navigation
Sany's reputation for manufacturing reliability translates directly into lower ownership costs. Parts availability through established channels means reduced downtime, while the brand's expanding global footprint ensures long-term serviceability and competitive resa
| Specifications | Value |
|---|---|
| No. | 1019750 |
| Tonnage (tons) | 87 |
| Working weight (kg) | 78600 |
| Bucket capacity (m³) | 5.0-6.5 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 377/1800 |
| Ground specific pressure (Kpa) | 114 |
| Rotation speed (rpm) | 7.7 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 432/469 |
| Rod digging force (kN) | 370/402 |
| Travel speed (km/h) | 4.5/2.9 |
| Total transport length (mm) | 13002 |
| Total transport width (mm) | 4320 |
| Total transport height (mm) | 4742 |
| Full cab height (mm) | 3795 |
| Minimum ground clearance (mm) | 880 |
| Minimum turning radius of front working device (mm) | 5586 |
| Back end turning radius (mm) | 4220 |
| Onboard width (mm) | 3460 |
| Total track length (mm) | 5946 |
| Track gauge (mm) | 3380 (Operation) /2780 (Transportation) |
| Track plate width (mm) | 650 |
| Track ground length (mm) | 4770 |
| Maximum height at minimum turning radius (mm) | 9802 |
| Maximum digging radius (mm) | 11703 |
| Maximum digging depth (mm) | 7247 |
| Maximum excavation height (mm) | 10910 |
| Maximum unloading height (mm) | 7047 |
| Maximum vertical digging depth (mm) | 6792 |
